ABB Bailey IPECB11 Circuit Breaker

The ABB Bailey IPECB11 protects incoming AC power lines for Bailey control equipment. This breaker mounts directly onto the power entry panel inside the system cabinet. It weighs approximately 0.35 kg and requires minimal panel space. Its dimensions measure 10.2 cm in length, 5.1 cm in width, and 6.4 cm in height.

Technical Specifications & Hardware Details

The IPECB11 features a single-pole thermal-magnetic trip mechanism for overcurrent protection. Two screw-type terminals accept line and load side wiring for easy connections. This unit stores no electrical energy because it contains no internal batteries. Three primary components form the complete breaker: the housing, the trip mechanism, and the manual reset lever.

Parameter	Specification
Product Model	IPECB11
Weight	0.35 kg (0.77 lbs)
Dimensions (L×W×H)	10.2 cm × 5.1 cm × 6.4 cm
Number of Components	3 assemblies (housing, trip mechanism, reset lever)
Pole Configuration	Single pole
Terminal Type	2 screw-type terminals
Trip Mechanism	Thermal-magnetic
Energy Storage	None (no batteries or capacitors)
Mounting Type	Panel-mount with two M3 screws

Current Ratings and Protection Features

This breaker carries a continuous current rating of 10 amperes at 250V AC. It trips within 0.1 seconds during short circuit conditions. For overload situations, the thermal element responds after a 5 to 30 second delay. The IPECB11 also provides a visual trip indicator on the front face.

Installation and System Integration

You can install this breaker on any standard DIN rail or directly on a panel. The manual reset lever pops to the OFF position after a fault occurs. This breaker operates reliably from -10°C to 60°C. Consequently, the IPECB11 requires no maintenance beyond periodic trip testing. Simply reset the lever after addressing the underlying electrical issue.
