ABB Bailey INIPL01-L Universal Fieldbus Interface Module

This fieldbus interface module connects ABB Bailey systems to多种 industrial communication networks. You will find the ABB Bailey INIPL01-L Universal Fieldbus Interface Module translating protocols between Infi-net and standard fieldbuses. Its flexible设计 supports Profibus, Modbus, and Foundation Fieldbus connections.

Technical Specifications

This module contains one Infi-net port and two configurable fieldbus interfaces. You can also locate eight DIP switches for network address and baud rate selection. The ABB Bailey INIPL01-L Universal Fieldbus Interface Module stores no battery energy for configuration retention. Instead, it uses flash memory for all protocol and mapping settings. Therefore, this module never requires any routine battery replacement.

Protocol Translation Details

The ABB Bailey INIPL01-L Universal Fieldbus Interface Module draws its operating power from the INFI 90 bus backplane. You can configure each fieldbus port independently for different protocol types. The module automatically maps process variables between network formats without programming. Moreover, the eight DIP switches set the node address and communication speed. This design allows quick integration of third-party field devices into Bailey systems.

Mechanical Integration and Mounting

You must insert the ABB Bailey INIPL01-L Universal Fieldbus Interface Module carefully into any standard INFI 90 slot. After full insertion, secure the module using the top and bottom metal retaining clips. The module measures exactly 25.5 centimeters in length and 3.2 centimeters in width. Its total weight reaches approximately 0.52 kilograms for straightforward handling. Furthermore, the five status LEDs provide immediate visual feedback for network diagnostics.

Environmental and Storage Guidelines

You should store this ABB Bailey INIPL01-L Universal Fieldbus Interface Module in an anti-static bag away from moisture. The module operates reliably between 0°C and +60°C ambient temperature. Likewise, keep the unit away from conductive dust or strong electromagnetic interference. Because the module uses solid-state components only, it requires zero regular maintenance over its service life.
