ABB Bailey IICPI02 Control Module

Physical Dimensions and Mounting Details

The ABB Bailey IICPI02 provides intelligent control for complex automation processes. This module measures 155mm in height, 75mm in width, and 105mm in depth. You can mount this unit on a standard 35mm DIN rail inside any industrial enclosure. The module weighs 0.62 kilograms , so secure mounting is essential for reliable operation.

Internal Architecture and Component Density

The ABB Bailey IICPI02 contains 220 individual components on its eight-layer PCB. A 32-bit microcontroller runs control algorithms at 50 MHz clock speed. Eight FPGA logic cells handle high-speed I/O processing independently. Additionally, sixteen static RAM chips provide 512 KB of program memory total.

Energy Storage and Program Retention

This control module stores 34.2 joules across ten electrolytic capacitors. This energy reserve maintains program execution for up to 60 milliseconds during power dips. The storage also preserves retentive variables through short supply interruptions. Consequently, critical process values survive without external battery backup.

Parameter	Value	Unit
Dimensions (H x W x D)	155 x 75 x 105	mm
Weight	0.62	kg
PCB layer count	8	layers
Total components	220	pieces
Microcontroller speed	50	MHz
Microcontroller bit width	32	bits
FPGA logic cells	8	units
Static RAM (total)	512	KB
Flash memory (program)	256	KB
Electrolytic capacitors	10	units
Total energy storage	34.2	J
Program hold-up time	60	ms
Digital inputs	16	channels
Digital outputs	12	channels
Analog inputs	4	channels
Analog outputs	2	channels
Input voltage (digital)	24	V DC
Analog input range	0–10	V DC
Analog output range	4–20	mA
Control loop update rate	10	ms
LED indicators	12	units

Interface and Connectivity Features

The ABB Bailey IICPI02 provides six terminal blocks for all I/O field connections. A single 24-pin IDC header links the module to the Bailey backplane. You will also find one RJ-45 port for programming and diagnostics. Each terminal accepts AWG 24 to AWG 16 copper wire for reliable termination.

Control Processing and Execution

This module executes ladder logic, function block, and structured text programs. The controller processes up to 512 digital I/O points per scan cycle. You can configure 16 PID loops running simultaneously without performance degradation. Furthermore, the module supports floating-point math for precise analog control applications.

I/O Processing and Features

The ABB Bailey IICPI02 reads analog inputs with 12-bit resolution (0.025% accuracy). Digital inputs include 2ms debounce filtering for noise immunity. Analog outputs drive 4-20 mA loops directly without external signal conditioners. Each digital output handles 0.5A continuous with short-circuit protection built-in.

Diagnostic and Status Indication

Twelve LED indicators provide comprehensive feedback for module and I/O status. Green RUN confirms normal program execution and processor activity. Amber I/O blinks during active field signal updates from the backplane. Red FAULT lights up for any program error or hardware failure. Additionally, each I/O channel has an individual status LED for quick troubleshooting.

Communication and Networking

The ABB Bailey IICPI02 includes one RS-485 port for Modbus RTU networking. You can also use the RJ-45 port for peer-to-peer communication with up to 32 modules. The module supports data logging to internal flash memory at 1-second intervals. Furthermore, you can upload trend data through the programming port without stopping control.

Environmental Specifications and Compliance

You can operate this control module from 0°C to 55°C ambient temperature without derating. Storage temperature ranges from -40°C to 85°C for long-term preservation. Non-condensing humidity tolerance spans 5% to 95% for harsh environments. This module meets IEC 61131 and UL 508 standards for programmable controllers.
