ABB 1SBP260024R1001 Advant Controller

The 1SBP260024R1001 serves as the main CPU for ABB Advant AC450 systems. This controller executes complex process control and sequencing tasks. It supports large-scale automation with high-speed processing.

Key Technical Specifications

Parameter	Value
Processor	32-bit RISC, 66 MHz
Program Memory	8 MB RAM (battery-backed)
Execution Speed	0.3 ms per 1K instructions
Data Memory	2 MB flags + 512 timers
Supply Voltage	24V DC ±20%
Power Consumption	25 W typical
Digital I/O Capacity	2048 channels max
Analog I/O Capacity	256 channels max
Communication Ports	Ethernet, RS-232, RS-485
Controller Dimensions	32.0 cm x 22.0 cm x 5.5 cm
Weight	3.5 kg (7.72 lbs)
Component Count	286 discrete components
Energy Storage	10000 µF bulk capacitance
Operating Temperature	0°C to 55°C

Physical Dimensions and Component Layout

This controller measures 32.0 cm in length and 22.0 cm in width. Its total height reaches 5.5 cm including the heat sink. 1SBP260024R1001 weighs 3.5 kg for robust rack mounting. You will find 286 discrete components on an eight-layer PCB.

Moreover, the controller integrates a 10000 µF bulk capacitor bank. This bank stores energy for 100 ms during power interruptions. It also filters heavy noise from the 24V DC supply rail.

Processing Performance and Memory

The 32-bit RISC processor executes 1K instructions in just 0.3 ms. This speed supports fast scan cycles for complex process control. The 8MB RAM stores large ladder logic and structured text programs. A lithium battery retains this memory for up to 365 days without power.

Communication and Networking

Built-in Ethernet supports TCP/IP and Modbus TCP protocols. Two serial ports provide RS-232 and RS-485 connectivity. You can expand I/O using up to 16 remote racks via fiber optic. The controller also supports Profibus DP and CANopen fieldbuses.

Typical Application Scenarios

You can deploy 1SBP260024R1001 in ABB Advant AC450 systems for large automation tasks. It also works well for power plants, chemical processing, and pulp mills. This controller handles batch control, advanced regulation, and data acquisition. Its 8MB memory suits applications with up to 2000 I/O points.
