ABB 1SAP220600R0001 PROFINET Bus Module

The 1SAP220600R0001 connects AC500 PLCs to PROFINET industrial networks. This module acts as a communication interface between the CPU and field devices. It supports real-time data exchange at high speeds.

Key Technical Specifications

Parameter	Value
Network Protocol	PROFINET IO (RT/IRT)
Data Rate	100 Mbps (full duplex)
Port Count	2-port integrated switch
Connector Type	2 x RJ45 (shielded)
Cycle Time	1 ms minimum
Supply Voltage	24V DC ±20%
Power Consumption	2 W typical
Module Dimensions	3.5 cm x 9.5 cm x 6.2 cm
Weight	0.14 kg (0.31 lbs)
Component Count	68 discrete components
Energy Storage	100 µF bulk capacitance
Operating Temperature	-20°C to 60°C

Physical Dimensions and Component Layout

This module measures 3.5 cm in length and 9.5 cm in width. Its total height reaches 6.2 cm including the connectors. 1SAP220600R0001 weighs just 0.14 kg for DIN rail mounting. You will find 68 discrete components on a six-layer PCB.

Moreover, the module integrates a 100 µF capacitor for supply filtering. This capacitor smooths noise on the 24V DC rail. It also provides brief hold-up during power interruptions.

Network Interface and Communication

Two RJ45 ports include an integrated 2-port switch. This switch allows daisy-chaining multiple devices without external hardware. The module supports PROFINET Real-Time and Isochronous Real-Time classes. Consequently, it handles motion control and high-speed automation tasks.

Configuration and Diagnostics

You can configure the module using ABB Automation Builder software. The module supports device names and IP address assignment via DCP. LED indicators show link status, port activity, and network errors. A built-in web server provides detailed diagnostic information.

Typical Application Scenarios

You can deploy 1SAP220600R0001 in ABB AC500 and AC500-S safety PLC systems. It also works well for distributed I/O and drive control networks. This module connects to PROFINET controllers, HMIs, and drives. Its 2-port switch saves space in compact control cabinets.
