ABB 1SAP170901R0001 Communication Module

This module enables serial communication between AC500 PLCs and external devices. The ABB 1SAP170901R0001 provides one configurable port for industrial network connections. It measures 45 mm in width and 70 mm in height. This unit weighs approximately 0.08 kg for DIN rail mounting.

Technical Specifications Table

Parameter	Value
Product Model	ABB 1SAP170901R0001
Brand	ABB
Category	Communication Module / Serial Interface
Compatible Series	ABB AC500
Number of Ports	1
Port Type	RS232/RS485 (9-pin SUB-D), software configurable
Baud Rate Range	300 to 115200 bps
Protocols Supported	Modbus RTU, Modbus ASCII, ABB CP400
Dimensions (W x H x D)	45 mm x 70 mm x 55 mm
Weight	0.08 kg
Connector Type	1 x 9-pin SUB-D
Internal Components	1 x UART, 1 x line driver, 1 x transceiver
Energy Storage	None (no battery required)
Electrical Isolation	500 V AC between port and backplane
Operating Voltage	5 V DC (from backplane)
Power Consumption	50 mA maximum
LED Indicators	1 x status (TX/RX activity)
Operating Temperature	0°C to 60°C

Internal Design and Communication Processing

This communication module uses a UART for serial data handling. A line driver converts logic levels to RS232 or RS485 signals. The ABB 1SAP170901R0001 supports Modbus RTU and Modbus ASCII protocols. You configure the port’s baud rate and protocol via PLC software. The module buffers incoming and outgoing data for the CPU. Consequently, this module enables reliable data exchange between PLCs and external devices.

Installation and Configuration Guide

First, mount this module onto a standard 35 mm DIN rail securely. Next, connect your serial device to the 9-pin SUB-D port using a shielded cable. Then, configure the port’s baud rate and protocol using AC500 configuration software. Use RS232 for short-distance connections up to 15 meters. Use RS485 for long-distance networks up to 1200 meters. The module automatically buffers incoming messages for the CPU. A single LED indicator shows transmit and receive activity. This communication module works with all AC500 CPU models including 1SAP140200R0160 and 1SAP140300R0160. Always terminate the RS485 line with proper resistors for long cable runs.
