Technical Specifications and Module Design
This communication module provides Ethernet connectivity for ABB AC500 and AC500-eCo PLC systems. The ABB 1SAP170800R0001 connects your controller to plant-wide industrial networks. You can mount this module directly onto the CPU or as a separate bus unit. Its compact design supports both local and remote I/O configurations. The module weighs approximately 0.12 kilograms. Its dimensions measure 9.5 cm in height, 6 cm in width, and 7 cm in depth.
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | 1SAP170800R0001 |
| Category | Communication Module / Ethernet Interface |
| Weight | 0.12 kg |
| Height | 9.5 cm |
| Width | 6 cm |
| Depth | 7 cm |
| Network Interface | 1 x RJ45 (10Base-T / 100Base-TX) |
| Communication Speed | 10/100 Mbps, auto-negotiating |
| Protocols Supported | Modbus TCP/IP, PROFINET IO, EtherNet/IP |
| Web Server | Built-in for diagnostics and monitoring |
| Maximum Connections | 8 simultaneous TCP/IP sockets |
| Configuration Method | Web browser or ABB Automation Builder |
| DHCP Support | Yes (client) |
| Email Notification | Yes (SMTP client) |
| Power Supply | 24V DC (from backplane or external) |
| Power Consumption | 1.5 Watts maximum |
| Energy Storage | None (no battery) |
| Component Count | Single PCB with Ethernet controller, magnetics, and processor |
Network Protocols and Data Exchange
The module supports Modbus TCP/IP for communication with SCADA and HMI systems. You can configure the module as a Modbus TCP server or client. The ABB 1SAP170800R0001 also acts as a PROFINET IO device for Siemens environments. EtherNet/IP support enables integration with Rockwell Automation systems. The built-in web server provides real-time diagnostics and status monitoring. A green LED indicates link status and network activity on the port. The module handles up to eight simultaneous client connections without performance loss.
Configuration and Diagnostics Features
You can configure the module using a standard web browser on any computer. The web interface displays module status, IP settings, and diagnostic counters. The ABB 1SAP170800R0001 supports DHCP for automatic IP address assignment. You can also assign a static IP address manually for fixed installations. The module generates email alerts for specific events like power loss. A yellow LED flashes when the module sends or receives data packets. The module stores configuration parameters in non-volatile flash memory.
Installation and Network Guidelines
You must mount this module on a standard 35 mm DIN rail in your cabinet. The module requires a 24V DC power supply for normal operation. The ABB 1SAP170800R0001 draws approximately 60 mA from the 24V supply rail. You must use shielded Cat5e or Cat6 cables for all Ethernet connections. These cables reduce electromagnetic interference from nearby industrial equipment. The module requires no external battery for normal network operation. You should assign a unique IP address before connecting to the plant network. The operating temperature ranges from -20°C to +60°C.
