ABB 07 AB 63 R1 Binary Output Module

This output module provides sixteen binary switching channels for field devices. The ABB 07 AB 63 R1 connects directly to solenoids, relays, and pilot lights. You can mount this module in any standard Procontic I/O rack slot. Its high channel density optimizes cabinet space utilization significantly.

Physical Dimensions and Hardware Layout

The ABB 07 AB 63 R1 measures 16.5 cm in overall width. Its total depth reaches 18.2 cm including the terminal hood. This binary output module weighs approximately 0.50 kg. A metal housing provides effective shielding against electromagnetic interference. One green LED indicates backplane power status. Additionally, sixteen red LEDs show each channel’s active switching state.

Output Specifications and Load Handling

Each output channel switches 24V DC loads up to 1.0A continuously. The ABB 07 AB 63 R1 provides a total module current of 8A maximum. Built‑in short circuit protection activates at 1.2A per channel. The module also features overtemperature shutdown for overload conditions. Outputs resume normal operation after fault removal automatically.

Parameter	Specification
Number of Channels	16
Output Type	Transistor (PNP, sourcing)
Load Voltage Range	18 to 30V DC
Output Current per Channel	1.0A continuous
Total Module Current	8A max
Short Circuit Trip Point	1.2A ±10%
On‑State Voltage Drop	< 0.7V at 1.0A
Off‑State Leakage	< 0.1 mA
Switching Speed (On)	0.3 ms typical
Switching Speed (Off)	0.4 ms typical
Dimensions (W x H x D)	165 mm x 90 mm x 182 mm
Weight	0.50 kg (1.10 lbs)
Terminal Type	Removable 20‑pin screw block
Wire Size	0.2 to 2.5 mm²
Number of Terminal Screws	20
Backplane Current Draw	250 mA @ 5V DC
Power Dissipation	5.5 W max at full load
Internal Energy Storage	150 µF capacitor bank
Protection Features	Short circuit, thermal, reverse polarity
LED Indicators	1 green (power), 16 red (channels)
Operating Temperature	0°C to +55°C

Energy Storage and Output Behavior

Internal capacitors maintain output states during brief power dips. The ABB 07 AB 63 R1 stores enough energy for 12 ms of hold‑up time. This storage prevents false output resets during short interruptions. All outputs revert to a safe state after a power failure longer than 12 ms.

Protection Circuits and Diagnostic Features

Short circuit protection limits current to 1.2A per channel automatically. Thermal shutdown activates when internal temperature exceeds 85°C. The ABB 07 AB 63 R1 reports overload events through a group error flag. The host controller can read this flag via the backplane interface. Additionally, reverse polarity protection prevents damage from incorrect wiring.

Wiring and Installation Guidelines

Connect field devices to the removable 20‑pin screw terminal block. The ABB 07 AB 63 R1 accepts solid or stranded wires from 0.2 to 2.5 mm². Use a common 24V DC supply for all output loads. Proper grounding reduces electrical noise significantly. Therefore, system reliability improves in industrial environments.
