140CPS12420C | Schneider Electric Power Supply Module

The Schneider Electric 140CPS12420C power supply module for the Modicon Quantum platform has the following detailed specifications and characteristics:

Main Product Information:

• Range: Modicon Quantum Automation Platform
• Product Type: Power Supply Module
• Power Supply Type: Redundant

Electrical Specifications:

• Input Voltage:
  • 115 V AC: 93…138 V, 47–63 Hz
  • 230 V AC: 170…276 V, 47–63 Hz
• Input Current:
  • 1100 mA at 115 V
  • 600 mA at 230 V
• Inrush Current:
  • 19 A at 230 V
  • 38 A at 115 V
• Rated Power: 130 VA
• Fuse Rating: 2 A, slow-blow
• Harmonic Distortion: <= 10% of the fundamental rms value

Output Specifications:

• Output Voltage: 5.1 V DC
• Output Current:
  • 11 A (at 60°C, standalone mode)
  • 10 A (at 60°C, redundant mode)
• Protection Features:
  • Overvoltage Protection: Internal
  • Overload Protection: Internal
• Power Dissipation: 6+(1.5×Iout)6 + (1.5 \times I_{out})6+(1.5×Iout​) W (where IoutI_{out}Iout​ is the output current in A)
• Alarm Output: 1 NC, 6 A, 220 V (Power supply fault)
• Local Signaling: Green LED (PWR OK)

Physical Specifications:

• Module Format: Standard
• Net Weight: 0.65 kg

Environmental and Compliance Information:

• Protective Treatment: Conformal coating (Humiseal 1A33)
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 95% (without condensation)
• Operating Altitude: ≤ 5000 m
• Electrostatic Discharge Resistance:
  • 4 kV (contact), conforming to IEC 801-2
  • 8 kV (air), conforming to IEC 801-2
• Resistance to Electromagnetic Fields: 10 V/m, 80…2000 MHz (conforming to IEC 801-3)

Certifications and Standards:

• Standards:
  • CSA C22.2 No 142
  • UL 508
• Product Certifications: cUL
• Marking: CE

Packing Information:

• Unit Type of Package: 1 PCE
• Number of Units in Package: 1
• Package Dimensions:
  • Height: 16.3 cm
  • Width: 4.5 cm
  • Length: 31.2 cm
• Package Weight: 800.0 g

Additional Notes:

• This power supply module is specifically designed for use in redundant power setups, providing 5.1 V DC output with high current capacity and internal protection features. It supports industrial automation in harsh environments, with compliance to global standards and protection against electrostatic discharge and electromagnetic interference.
