Yokogawa SNT501-13 Optical Bus Repeater

The Yokogawa SNT501-13 Optical Bus Repeater Module is designed to extend communication between devices using optical fiber technology. This module improves the reach and reliability of your system’s communication network. With support for both star and chain-type connections, it is ideal for expanding industrial automation systems.

Key Features

Optical Fiber Transport: Transmits ESB Bus signals over optical fiber, ensuring reliable and fast data transfer.
Connection Flexibility: The module supports both star and chain network configurations, offering versatility in system design.
Extended Range: Capable of covering distances up to 50 km in two stages, improving network scalability.
Low Power Consumption: Consumes only 0.5 A, providing an energy-efficient solution for your network expansion needs.

Technical Specifications

Parameter	Value
Model Number	SNT501-13
Function	Optical Bus signal repeater
Connection Type	Star type, chain type
Transmission Distance	5 km to 50 km (two stages)
Current Consumption	0.5 A
Weight	Approx. 0.3 kg

Applications

The Yokogawa SNT501-13 module is ideal for use in a wide range of industrial applications:

Industrial Automation: Expands communication across large-scale automation systems.
Process Control Systems: Extends signal reach to ensure consistent data transmission over long distances.
Network Expansion: Perfect for extending ESB Bus networks in manufacturing plants and large industrial facilities.

Conclusion

The Yokogawa SNT501-13 Optical Bus Repeater Module enhances the flexibility and performance of your industrial network. With reliable optical fiber transport, flexible connection options, and long-distance transmission, it ensures seamless communication in even the most demanding industrial environments.
