Yokogawa PW604 DC Output Power Module

The Yokogawa PW604 is a reliable and high-performance DC output power module, designed to meet the power requirements of various industrial automation systems. It provides a stable and efficient power source to control systems, sensors, and other essential components in diverse applications.

Key Features of the Yokogawa PW604

Efficient DC Power Output: The PW604 offers reliable DC power for industrial automation and control applications. It delivers consistent voltage and current to connected systems for optimal performance.
Wide Input Voltage Range: The module supports a broad input voltage range of 198 to 264 VAC, making it adaptable to various power sources.
High Power Capacity: With a rated output of 24 V DC, the PW604 provides sufficient power for controlling complex industrial systems.
Compact and Reliable Design: The PW604 features a compact form factor, designed to fit seamlessly into a range of industrial systems, without sacrificing reliability or performance.
Built-in Protection: The module includes built-in safety features, such as overvoltage, overcurrent, and short-circuit protection, ensuring the safety of both the power module and connected devices.

Technical Specifications

Specification	Value
Input Power Supply Voltage	198-264 VAC, 50/60 Hz
Max. Input Current	1.25 A
Power Consumption	220 VA
Rated Output Voltage	24 V DC ±5%
Rated Output Current (0-50°C)	6 A (total of 1st and 2nd outputs)
Rated Output Current (50-60°C)	4 A (total of 1st and 2nd outputs)
Withstanding Voltage	1500 VAC between input and FG terminal
Operating Temperature Range	0°C to 60°C
Output Hold-up Time	20 ms
Indication	READY LED (green): Lights up when in normal operation

Applications of the Yokogawa PW604

The Yokogawa PW604 is ideal for various industrial automation applications, including:

Manufacturing Systems: Powers critical control systems and automation modules to ensure uninterrupted operations.
Process Control Systems: Provides reliable power for process control units in chemical, oil, and gas industries.
Data Acquisition: Ensures stable and continuous power to data acquisition and monitoring systems in various industries.
Power Generation: Supplies power to control systems in power plants, ensuring smooth operation and safety.

Why Choose the Yokogawa PW604?

The PW604 power module stands out for its efficiency, reliability, and versatile design. It ensures continuous, stable power, while also offering built-in protections for safe operation. The PW604 is the perfect solution for high-demand applications that require a robust power supply.
