Yokogawa EC401 ESB Bus Coupler Module

The Yokogawa EC401 is a high-performance ESB Bus Coupler Module designed to facilitate smooth and efficient communication between different devices within industrial automation systems. By coupling the ESB network to other industrial devices, this module ensures seamless data transfer, enhancing the overall system performance.

Key Features of the Yokogawa EC401 ESB Bus Coupler Module

Efficient Communication: The EC401 enables stable communication between devices, ensuring quick and reliable data transfer across the ESB network.
Seamless Integration: It supports integration with various industrial equipment, reducing installation time and complexity.
Industrial Durability: Built with robust materials, the EC401 is engineered to withstand harsh industrial environments, ensuring long-term performance.
High Compatibility: This module supports a wide range of industrial devices and is ideal for use in various control and automation systems.
Compact and Space-Saving: Its compact size makes the EC401 easy to install in tight spaces, offering flexibility in system design.

Technical Specifications

Feature	Specification
Model	EC401
Type	ESB Bus Coupler Module
Power Supply	24V DC ±20%
Operating Temperature	-20°C to +60°C
Dimensions	150 mm x 120 mm x 50 mm
Weight	0.8 kg
Mounting Type	DIN Rail Mountable
Communication Protocol	ESB Communication Protocol
Data Transfer Rate	1 Mbps
Isolation Voltage	500 V DC
Input/Output Signals	4 digital inputs, 4 digital outputs
LED Indicators	Status LEDs for communication and power indication
Diagnostic Features	Provides built-in diagnostics for easier troubleshooting

Why Choose the Yokogawa EC401 ESB Bus Coupler Module?

Seamless Integration: The Yokogawa EC401 easily integrates with a wide variety of industrial devices, enhancing system flexibility.
Durable Performance: Designed to withstand industrial environments, this module delivers consistent performance over time.
Compact Design: Its small form factor ensures easy installation even in space-constrained systems, making it ideal for applications with limited space.
High-Speed Communication: With a data transfer rate of 1 Mbps, the EC401 ensures fast and reliable communication between devices.
Enhanced Diagnostic Capabilities: The EC401 provides built-in diagnostic features, which help detect issues early and improve system uptime.

Applications of the Yokogawa EC401 ESB Bus Coupler Module

The Yokogawa EC401 is ideal for a wide range of industrial applications, such as:

Industrial Automation: Perfect for connecting various devices and systems in a manufacturing plant or production line.
Building Automation: Suitable for integrating smart building systems such as HVAC, lighting control, and security systems.
Process Control: Ideal for use in process industries where real-time data exchange is critical for optimal performance.
Energy Management: Used in energy monitoring and control systems, offering reliable communication between energy meters, sensors, and controllers.
