The Yokogawa ADV151-P03/D5A00 is a high-performance digital input module, specifically designed for the CENTUM VP Distributed Control System (DCS). It efficiently captures binary signals from various devices, including pushbuttons, limit switches, and sensors. With 32 input channels, this module is ideal for large-scale industrial automation systems. Furthermore, it provides full electrical isolation between channels, ensuring reliable and safe operation. The ADV151-P03/D5A00 mounts easily onto a DIN rail, simplifying integration into CENTUM VP field control units (FCUs).
Technical Specifications
The Yokogawa ADV151-P03/D5A00 offers robust and precise technical specifications. Below is a detailed breakdown of its capabilities:
| Specification | Details |
|---|---|
| Model | ADV151-P03/D5A00 |
| Type | Digital Input Module |
| Input Channels | 32 channels |
| Rated Input Voltage | 24 V DC (sink/source) |
| Input ON Voltage Range | 18 to 26.4 V DC |
| Input OFF Voltage | Typically less than 2 V DC |
| Electrical Isolation | Full isolation between input channels and the system |
| Mounting | DIN rail |
| Dimensions (WxDxH) | 10.6 cm x 3.2 cm x 13 cm |
| Weight | 0.3 kg |
| Input Signal Types | Current: 4-20 mA DC; Voltage: 1-5 V DC (hardware-dependent) |
| Accuracy | 0.1% of full scale |
| Resolution | 16 bits |
| Power Consumption | 5 V DC, 0.4 A |
| Connection | Pressure clamp terminal block (ADV151-P03) with dedicated cable |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Operating Humidity | 5 to 95% RH, non-condensing |
Key Features & Benefits
- Reliable Accuracy & Resolution: The ADV151-P03/D5A00 provides 16-bit resolution with an accuracy of 0.1% of full scale, ensuring precise signal measurement for even the most demanding applications.
- Energy-Efficient: This module operates with low power consumption (5 V DC, 0.4 A), making it an energy-efficient choice for large-scale automation systems.
- Versatile Input Options: It supports both current (4-20 mA) and voltage (1-5 V DC) input types, offering flexibility for various industrial applications.
- Wide Environmental Compatibility: The ADV151-P03/D5A00 performs well in temperatures ranging from 0 to 50°C and with humidity levels from 5% to 95% RH. This makes it a reliable option for use in diverse industrial environments.
In summary, the Yokogawa ADV151-P03/D5A00 digital input module is engineered to meet the demands of industrial automation. It guarantees precision and safety, ensuring smooth and efficient operation within the CENTUM VP DCS.
