The Yokogawa ADM55R Relay Output Module ensures reliable control in industrial automation systems. It connects control systems with external devices through high-quality relay outputs. Designed for efficiency and durability, this module is an ideal solution for demanding industrial environments.
Key Features of the Yokogawa ADM55R Relay Output Module
The Yokogawa ADM55R comes equipped with several advanced features, ensuring it performs well in various industrial settings. It stands out because of its reliable performance, compact size, and comprehensive technical specifications.
Technical Specifications:
| Specification | Details |
|---|---|
| Model | Yokogawa ADM55R |
| Number of Relay Outputs | 8 Outputs |
| Relay Type | SPDT (Single Pole Double Throw) |
| Maximum Switching Voltage | 250V AC / 30V DC |
| Maximum Switching Current | 5A AC / 5A DC |
| Coil Voltage | 24V DC |
| Input Voltage Range | 20.4V to 26.4V |
| Power Consumption | 1.5W (Max) |
| Response Time | 10 ms |
| Contact Resistance | 100 mΩ (Max) |
| Weight | 0.3 kg |
| Dimensions | 80 mm x 120 mm x 40 mm |
| Mounting Type | DIN Rail |
| Ambient Temperature | -10°C to 60°C |
| Humidity Range | 5% to 95% (Non-condensing) |
| Status Indicators | LED Indicators for Power, Output Status |
| External Connections | Screw Terminals |
| Relay Protection | Diode Protection for Inductive Loads |
Advantages of the Yokogawa ADM55R Relay Output Module
- Reliable Performance: The Yokogawa ADM55R provides excellent reliability, offering a maximum switching current of 5A AC/DC. As a result, it can easily control various industrial devices.
- Fast Response: With a rapid response time of just 10 ms, this module delivers quick switching, making it highly suitable for high-speed industrial processes.
- Flexible Integration: The Yokogawa ADM55R features SPDT relays and is compatible with both 250V AC and 30V DC voltage options. This flexibility makes it easy to integrate into multiple systems.
- Compact Design: At only 0.3 kg, the Yokogawa ADM55R has a compact footprint. Furthermore, it mounts easily on a DIN rail, saving valuable panel space.
- Protection Features: Thanks to its diode protection for inductive loads, the Yokogawa ADM55R helps prevent damage from voltage spikes, ensuring a long lifespan.
Applications of the Yokogawa ADM55R Relay Output Module
The Yokogawa ADM55R Relay Output Module is perfect for a wide range of industrial automation applications, including:
- Control Systems: It is widely used for controlling external devices such as motors, solenoids, and valves within automated control systems.
- Manufacturing Automation: Ideal for integration with PLCs and SCADA systems in manufacturing plants, it enables reliable and real-time relay switching.
- Process Control: In process industries, the Yokogawa ADM55R plays a key role in switching control to ensure smooth machine and equipment operations.
Conclusion
The Yokogawa ADM55R Relay Output Module provides reliable, efficient, and fast relay outputs for industrial automation. Its small size, fast response time, and protection features ensure smooth and safe operation in various applications.
