Yokogawa ADM51C Contact Output Module

The Yokogawa ADM51C is a contact output module designed for seamless integration with Yokogawa CENTUM CS 3000 and CENTUM CS 1000 distributed control systems (DCS). This module provides reliable digital output with 16 points, making it ideal for industrial automation and process control applications. With its advanced features and robust performance, the ADM51C ensures efficient operation and reliable control in demanding environments.

Key Features:

Model: ADM51C
Category: Contact Output Module
Manufacturer: Yokogawa
Type: Transistor Contact Output

The ADM51C offers 16 points of digital output, each capable of providing transistor contact signals. It is specifically designed to support resistive and inductive loads, ensuring versatility across a wide range of industrial applications. Additionally, the module features an adjustable pulse width, allowing users to fine-tune the output to meet specific system requirements.

Technical Specifications:

Parameter	Details
Model	ADM51C
Number of I/O Points	16 digital output points
Output Signal	Transistor contact
Contact Rating (Resistive Load)	30 V DC, 100 mA or less
Contact Rating (Inductive Load)	30 V DC, 100 mA or less
Pulse Width	Adjustable from 0.1 to 7200 seconds
Pulse Width Resolution	20 milliseconds
Current Consumption	600 mA or less at 5.0 V DC

Why Choose the Yokogawa ADM51C?

High-Performance Output: The ADM51C supports up to 16 digital output points with reliable transistor contact signals, providing efficient control in DCS systems.
Versatility in Load Handling: It supports both resistive and inductive loads, ensuring compatibility with a wide range of industrial equipment.
Customizable Pulse Width: The pulse width is adjustable from 0.1 to 7200 seconds, offering flexible control for various application needs.
Low Power Consumption: With a maximum current consumption of 600 mA at 5 V DC, the ADM51C offers energy-efficient performance.

Applications:

The Yokogawa ADM51C is ideal for various industrial automation and process control applications, including:

Distributed Control Systems (DCS): Specifically designed for use with Yokogawa CENTUM CS 3000 and CENTUM CS 1000 systems, providing reliable output control.
Automation Systems: Perfect for controlling digital signals in automated industrial environments.
Process Control: Used in controlling output signals for processes that require precise timing and load handling.

With its reliable performance, energy-efficient design, and customizable features, the ADM51C is an essential component for any advanced distributed control system.
