Yokogawa AAV142-S00 Analog Input Module

The Yokogawa AAV142-S00 is a versatile, high-performance analog input module designed to integrate seamlessly with the Yokogawa ADEX-300 series process controllers. With 16 channels of input, this module supports multiple sensor types and offers excellent flexibility for a range of industrial applications.

Key Features and Technical Specifications

The Yokogawa AAV142-S00 provides outstanding accuracy, speed, and resolution, making it an ideal choice for demanding control systems.

Technical Specifications

Specification	Details
Manufacturer	Yokogawa
Model	AAV142-S00
Product Type	Analog Input Module
Number of Channels	16
Input Range	+10 V, ±5 V, +2.5 V, ±1 V, +0.5 V
Resolution	16 bits
Accuracy	±0.05% of full scale
Sampling Rate	Up to 1000 samples per second
Input Impedance	1 MΩ
Output Impedance	100 Ω
Power Supply	12 V DC
Dimensions (L x W x H)	120 mm x 110 mm x 25 mm
Weight	0.5 kg (1.1 lbs)

Product Description

The Yokogawa AAV142-S00 is designed to provide precise analog input for a variety of industrial sensors. With its 16 input channels, this module allows you to connect a wide range of sensor types, including voltage and current sensors. The input range supports +10 V, ±5 V, +2.5 V, ±1 V, and +0.5 V, offering significant flexibility for diverse applications.

This module boasts 16-bit resolution, ensuring that even the smallest variations in input signals are captured accurately. The sampling rate of up to 1000 samples per second ensures real-time performance, even in high-speed applications.

The accuracy of ±0.05% of full scale guarantees high precision for critical applications. Furthermore, the Yokogawa AAV142-S00 features on-board signal conditioning, including amplification, filtering, and offset correction, ensuring high-quality signal processing.

High Accuracy and Resolution

The Yokogawa AAV142-S00 delivers high accuracy with an impressive ±0.05% of full scale. Combined with its 16-bit resolution, the module ensures precise data capture, which is crucial for sensitive industrial applications.

Fast Sampling Rate

With a sampling rate of up to 1000 samples per second, the Yokogawa AAV142-S00 ensures real-time data acquisition, ideal for high-speed processes that require rapid response times.

Easy Integration and Usage

The Yokogawa AAV142-S00 is designed for easy configuration and integration into industrial systems. Its 12 V DC power supply and simple interface make installation quick and straightforward.

On-Board Signal Conditioning

The module includes on-board signal conditioning for signal amplification, filtering, and offset correction. These features enhance signal quality and improve overall system performance.

Applications

The Yokogawa AAV142-S00 is suitable for use in various applications, including:

Industrial Automation: For real-time monitoring and control of process variables.
Measurement Systems: For high-accuracy voltage and current measurement in testing environments.
Energy Management: Effective in energy monitoring systems requiring precise analog data input.
Environmental Monitoring: Suitable for collecting analog signals from sensors in environmental control systems.
