Woodward 5466-1000 MicroNet Plus Digital Controller

The Woodward 5466-1000 MicroNet Plus Digital Controller is a highly reliable power supply module designed for industrial automation systems. This unit is specifically engineered to handle a variety of applications, including control of hydro, gas, and steam turbines, as well as gas and diesel engines. It can be used with MicroNet-Plus models, offering either simplex or redundant CPU configurations for added flexibility and redundancy.

Key Features and Functions

The 5466-1000 module integrates seamlessly into your system, occupying up to two slots for installation. It provides stable power supply to connected systems and supports a wide range of applications, including energy generation and automation. The MicroNet Plus Digital Controller supports 24 VDC input voltage and has a maximum power consumption of 15 W (13.5 W typical), ensuring efficient operation.

Equipped with RS-485 ports, the 5466-1000 facilitates communication between components, and it features a fault indicator LED to alert users of potential issues. When the LED is solid red, it indicates a communication error between the CPU and actuator. If the LED flashes, an internal issue occurs, and replacing the unit is recommended.

Technical Specifications

Specification	Details
Model	5466-1000
Category	MicroNet Plus Digital Controller
Input Voltage	24 VDC (LVD and UL certified)
Power Consumption	Max. 15.0 W, Typical 13.5 W
Operating Temperature	0°C to +55°C
Weight (with Chassis)	48 lbs. (22 kg)
RS-485 Ports	Up to 3
Manufacturer	Woodward Inc., Fort Collins, CO
Manuals	26167V1 and 26166V2

Installation Guidelines and Environmental Considerations

The 5466-1000 module is designed for easy installation into your MicroNet-Plus control system. When installing the unit, ensure that the edges of the circuit board align correctly. Slowly insert the module into the designated slots until the connectors engage with the motherboard and other modules. Always disconnect the power supply before beginning installation to avoid any electrical damage.

Operating within a temperature range of 0°C to +55°C, this unit is suitable for a wide variety of industrial environments. Make sure the installation area has proper ventilation to maintain optimal performance.

Applications and Compatibility

The 5466-1000 is ideal for use in power generation systems, including hydro, gas, and steam turbines, as well as internal combustion engines. Its MicroNet Plus compatibility ensures that it can be used with both simplex and redundant CPU configurations. The unit is also certified for use in SIL-approved safety systems, offering reliable performance in critical industrial applications.

Manufacturer

Woodward Inc., based in Fort Collins, Colorado, is a global leader in the development of power generation and control systems. Their MicroNet Plus Digital Controllers, like the 5466-1000, are trusted worldwide for their high reliability and advanced features in managing complex industrial systems.
