Woodward 5461-290 High Voltage Power Supply Module

The 5461-290 power supply module is a high-performance unit designed to meet the demanding needs of industrial automation systems. This open-frame module features multiple output voltages, including 24V, 211V, and 15V, ensuring versatility across a range of applications. It provides stable power for various industrial components, making it ideal for control systems, relays, and instrumentation.

Key Features and Functions

The 5461-290 delivers reliable power with three output voltages: 24V (for meter and actuator), 211V (for relay and fault signal), and 15V (for transmitter). This wide voltage range makes the module highly adaptable, suitable for various industrial automation systems. The open-frame design ensures effective cooling and easy integration into equipment.

Additionally, the module features LED status indicators, providing real-time monitoring of system health. This feature allows operators to quickly identify any potential issues and ensure the system runs smoothly without interruptions.

Technical Specifications

Specification	Details
Model	5461-290
Power Output Voltages	24V (Meter/Actuator), 211V (Relay/FS), 15V (Transmitter)
Design	Open Frame
LED Indicators	Yes, for status monitoring
Weight	Approx. 2 lbs
Dimensions (L x W x H)	100 mm x 80 mm x 45 mm
Power Input	120V AC
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Manufacturer	Woodward

Installation and Environmental Considerations

The 5461-290 is designed for easy integration into industrial systems, thanks to its open-frame construction. Its compact dimensions—100 mm (L) x 80 mm (W) x 45 mm (H)—make it suitable for tight spaces. The module operates efficiently in a temperature range of -20°C to 50°C (-4°F to 122°F), ensuring reliable performance in most industrial environments.

For optimal performance, install the module in a dry, dust-free area with sufficient airflow to avoid overheating.

Applications and Compatibility

The 5461-290 is perfect for use in industrial automation systems that require multiple output voltages. Its ability to deliver 24V, 211V, and 15V makes it suitable for a wide variety of applications, including metering, control relays, and transmitter power. It integrates seamlessly into systems that require stable and reliable power sources.

Manufacturer

Woodward is an established leader in industrial automation, providing high-quality power supply solutions like the 5461-290 to industries worldwide. The company’s commitment to innovation ensures their products meet the highest standards of performance and reliability.
