Triconex 3624 Supervised Digital Output Module

The Triconex 3624 is a supervised digital output module designed for use in safety-critical systems that require high reliability and fault tolerance. It integrates seamlessly into Triconex’s Triple Modular Redundancy (TMR) architecture, ensuring maximum safety and operational integrity in industries like oil & gas, chemical processing, and power generation.

Key Features of the Triconex 3624 Supervised Digital Output Module

• Supervised Digital Output: The Triconex 3624 operates as a supervised digital output module, providing high reliability for controlling field devices such as valves, alarms, and actuators. It integrates into safety instrumented systems (SIS) to ensure consistent performance.
• Voltage Range: It supports a voltage range from 16 to 30 VDC, with a nominal operating voltage of 24 VDC, making it suitable for a wide range of industrial applications.
• High Surge Protection: The Triconex 3624 can handle surge currents up to 4.8A per 10 ms, protecting the system from sudden voltage spikes and ensuring uninterrupted operation.
• Low Voltage Drop: With a typical voltage drop of less than 1.5 VDC, the Triconex 3624 ensures minimal power loss and improves overall system efficiency.
• Point Isolation: This module provides excellent point isolation with 1,500 VDC, helping prevent faults in one point from affecting the rest of the system.
• Low Power Consumption: The Triconex 3624 consumes less than 10 watts of power in operation, providing an energy-efficient solution for demanding industrial environments.
• Diagnostic Indicators: The Triconex 3624 offers comprehensive diagnostic feedback, including PASS, FAULT, ACTIVE, POWER, and LOAD indicators for each point. These help operators monitor the system’s health in real time.
• Color Coding for Easy Identification: The module is color-coded turquoise green, making it easy to identify and install correctly in complex control systems.

Technical Specifications

Applications

The Triconex 3624 is specifically designed for industries that require robust, fault-tolerant systems:

• Oil & Gas: Ideal for safety systems that need to manage critical assets and prevent downtime in hazardous environments.
• Chemical Processing: Ensures reliable control of safety systems in chemical plants, where safety and performance are paramount.
• Power Generation: Provides stable, high-performance digital output control for power plants, ensuring safe operation of key equipment.
• Manufacturing and Automation: Enhances industrial automation by controlling field devices reliably, improving operational efficiency and safety.
