Triconex 2652-9 7400058-390 Terminal Board

The Triconex 2652-9 7400058-390 terminal board serves as a reliable interface between field devices and the Triconex Safety Instrumented System (SIS). Equipped with 32 isolated input channels, it handles a wide variety of signal types. This makes it highly suitable for safety-critical applications where performance and reliability are essential. Furthermore, the terminal board features advanced diagnostics, hot-swappable capabilities, and robust communication protocols, ensuring seamless operation even in harsh industrial environments.

Key Features of the Triconex 2652-9 7400058-390 Terminal Board

Signal Versatility: The terminal board supports dry contact, wet contact, and pulse signals, offering flexibility across various field devices.
High Point Isolation: With 1500 VDC to 2500 VDC isolation, it guarantees strong protection for each input, safeguarding against faults and interference.
Advanced Diagnostics: It constantly monitors the health of the system, allowing quick detection of faults and reducing downtime.
Hot-Swappable Modules: This feature enables users to replace faulty modules without disrupting ongoing operations, ensuring continuous system performance.
Enhanced Communication: The terminal board employs high-integrity communication protocols to ensure data accuracy and system reliability, even in critical environments.

Technical Specifications of the Triconex 2652-9 7400058-390 Terminal Board

Specification	Details
Model	2652-9 7400058-390
Manufacturer	Triconex (Schneider Electric)
Module Type	Terminal Board
Input Channels	32 isolated input channels
Signal Types	Dry contact, wet contact, pulse signals
Input Voltage Range	90-155 VAC/VDC
Input Current Range	6-9 mA
Point Isolation	1500 VDC to 2500 VDC
Power Consumption	2.9 W
Dimensions (L x W x H)	173 x 117 x 48 mm (6.8 x 4.6 x 1.9 in)
Weight	0.4 kg (0.9 lb)
Operating Temperature Range	-40°C to +85°C (-40°F to 185°F)
Humidity Range	5 to 95% non-condensing
Vibration Resistance	2 g, 5 to 500 Hz
Shock Resistance	30 g, 11 ms

Applications of the Triconex 2652-9 7400058-390 Terminal Board

The Triconex 2652-9 7400058-390 terminal board is indispensable in industries that require secure connections between field devices and safety systems. Its versatile features make it a perfect choice for:

Chemical Processing: It enables reliable control of field devices in critical chemical processes, ensuring safety and efficiency.
Oil & Gas: The terminal board supports safe and precise signal termination in upstream and downstream operations.
Power Generation: It integrates seamlessly with safety systems, ensuring continuous and secure operation in power plants.
Manufacturing: The terminal board helps streamline automation processes, enabling reliable communication between machines and controllers.

Benefits of the Triconex 2652-9 7400058-390 Terminal Board

Flexibility: Supports multiple signal types, making it adaptable to various system configurations.
Reliability: The high point isolation and robust diagnostics ensure that the system remains operational without interruptions.
Ease of Integration: The terminal board integrates effortlessly with Triconex safety systems, providing a reliable solution for process control.
Durability: Built to endure harsh industrial environments, it offers long-term reliability and low maintenance.
Enhanced Safety: Provides secure and safe operation with advanced diagnostic features and fault isolation.
