Siemens 6ES7807-3BA01-0YA1 | PRODAVE MPI MINI V6.0

The Siemens 6ES7807-3BA01-0YA1 is a software package for PRODAVE MPI MINI V6.0, a data exchange tool for SIMATIC S7 controllers. This software enables PC applications to communicate with S7-200, S7-300, and S7-400 PLCs. It provides a simple programming interface for reading and writing process data. Furthermore, the package supports MPI (Multi-Point Interface) communication for flexible connectivity. The software simplifies data integration between office and automation systems.

Easy-to-Use Programming Interface

This software offers a straightforward API for integrating PLC data into PC applications. The Siemens 6ES7807-3BA01-0YA1 supports Visual Basic, C++, and Delphi programming languages. It includes sample programs and documentation for rapid application development. Moreover, the software provides functions for reading and writing variables, blocks, and diagnostic data. This comprehensive interface reduces development time and effort significantly.

Reliable MPI Communication

The software uses MPI protocol for communication with S7 controllers. The Siemens 6ES7807-3BA01-0YA1 supports MPI communication with baud rates up to 187.5 kbps. It connects to Siemens PC adapters and CP cards for hardware interface. Furthermore, the software manages multiple connections for monitoring and control applications. This connectivity enables data exchange without requiring additional hardware or special configuration.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Model	Siemens 6ES7807-3BA01-0YA1
Product Type	PRODAVE MPI MINI V6.0 Software
Series	SIMATIC S7
Order Number	6ES7807-3BA01-0YA1
Supported PLCs	S7-200, S7-300, S7-400
Protocol	MPI
Baud Rate	Up to 187.5 kbps
Programming Languages	Visual Basic, C++, Delphi
Functions	Read/write variables, data blocks, diagnostics
Licensing	Single-user license
Delivery Format	CD-ROM
Operating System	Windows 9x, NT, 2000, XP

System Requirements and Compatibility

This software requires a PC with a compatible MPI interface and driver. The Siemens 6ES7807-3BA01-0YA1 supports Windows 95, 98, NT, 2000, and XP operating systems. It works with Siemens PC adapters (MPI) and CP communication cards. Furthermore, the software is compatible with PRODAVE V6.0 libraries and examples. Users can refer to the provided documentation for installation and configuration guidance.

Applications and Industries

The software serves applications requiring data exchange between PLCs and PC systems. It commonly appears in manufacturing execution systems (MES) and data acquisition. The software also supports production monitoring, quality control, and maintenance applications. Its simplicity makes it suitable for both automation engineers and IT professionals.
