Siemens 6ES7292-1BF30-0XA0 S7-1200 Terminal Block

Reliable Connection Solution for S7-1200 I/O Modules

This I/O terminal block provides a secure and maintainable wiring interface for S7-1200 systems. It facilitates quick replacement of worn or damaged connectors without rewiring. The Siemens 6ES7292-1BF30-0XA0 features a 10-pin connector design for signal and power distribution. It supports both digital and analog signal connections for versatile applications. The terminal block uses a screw-type clamping mechanism for reliable wire retention. It maintains compatibility with all S7-1200 signal modules.

Physical Dimensions and Construction Details

The unit measures 50 mm in height, 35 mm in width, and 60 mm in depth. It weighs approximately 0.05 kg with all clamping elements and housing included. The 6ES7292-1BF30-0XA0 plugs directly into the front of the I/O module. Its robust polyamide housing provides excellent insulation and mechanical strength. This compact design supports dense wiring configurations in control cabinets.

Interface Connectivity and Electrical Specifications

A 10-pin male connector interfaces with the mating socket on the I/O module. The Siemens 6ES7292-1BF30-0XA0 accommodates wire sizes from 0.25 mm² to 1.5 mm². It features a screw-type termination for each connection point. The terminal block handles signals up to 24 V DC and 2 A per pin. A strain relief mechanism prevents cable pull-out from the connector body.

Internal Architecture and Component Specifications

The terminal block contains conductive contact pins and clamping screw assemblies. The 6ES7292-1BF30-0XA0 includes a protective cover for the connection points. It incorporates a keying feature to prevent incorrect insertion. The housing material meets UL 94 V-0 flammability standards. Gold-plated contact surfaces ensure reliable signal transmission over time.

Parameter	Specification
Model	6ES7292-1BF30-0XA0
Type	I/O Terminal Block
Connector Type	10-pin male
Compatibility	SIMATIC S7-1200 signal modules
Termination Type	Screw-type clamp
Wire Size	0.25–1.5 mm²
Rated Voltage	24 V DC
Rated Current	2 A per pin
Contact Material	Gold-plated copper alloy
Dimensions (H×W×D)	50 × 35 × 60 mm
Weight	0.05 kg
Operating Temperature	–20 to +60 °C
Storage Temperature	–40 to +85 °C
Housing Material	Polyamide (UL 94 V-0)
Protection Class	IP20

Recommended Installation and Replacement Practices

Insert the Siemens 6ES7292-1BF30-0XA0 into the I/O module socket with proper alignment. Tighten the clamping screws to the specified torque rating for reliable connections. Replace the terminal block without disturbing existing wiring when necessary. Verify all connections are secure before applying power to the system. Use the correct wire stripping length for optimal clamping performance. Store spare terminal blocks in a clean and dry environment.
