Siemens 6ES7272-0AA00-0YA0 TD 200

Compact Operator Interface for S7-200 Systems

The Siemens 6ES7272-0AA00-0YA0 provides a TD 200 text display operator panel for the SIMATIC S7-200 PLC system. This compact interface enables operators to view process data and acknowledge alarms directly from the field. It connects easily to the S7-200 through the PPI interface. Its simple design makes it ideal for basic machine-level HMI tasks.

Key Technical Specifications

Parameter	Specification
Product Model	Siemens 6ES7272-0AA00-0YA0
Brand	Siemens
Category	Operator Interface / Text Display
Product Family	SIMATIC S7 (for S7-200 systems)
Display Type	Backlit LCD
Number of Lines	2 lines of text
Characters per Line	16 characters (alphanumeric)
Function Keys	8 configurable function keys
Interface	PPI (Point-to-Point Interface)
Communication Speed	9.6 kbps to 187.5 kbps
Power Supply	24 VDC
Current Consumption	150 mA
Mounting	Panel mount
Dimensions	144 mm x 72 mm x 44 mm (approx.)
Weight	Approx. 200 g
Operating Temperature	0°C to 55°C
Storage Temperature	-40°C to 70°C
Protection Class (Front)	IP65

User Interface and HMI Functionality

The Siemens 6ES7272-0AA00-0YA0 provides a clear and simple operator interface. The 2-line, 16-character display shows process values and alarm messages. The 8 configurable function keys allow operators to control the machine. The device supports multiple languages.

System Integration and Communication

This text display connects to the S7-200 via the PPI interface. Users can configure the display’s communication parameters. The display can be used as a stand-alone HMI or as part of a larger network.

Physical Design and Installation

The device features a front panel with IP65 protection, making it suitable for industrial environments. It requires a panel cutout for installation. The device is lightweight and easy to install.

Application Suitability

This text display is ideal for small to medium-sized machines and simple processes. It is suitable for applications where a full-featured HMI is not required. The device provides a cost-effective solution for basic operator tasks.
