Siemens 6ES5465-4UA11 Analog Input Module

The Siemens 6ES5465-4UA11 Analog Input Module is specifically designed to process analog signals in industrial automation systems. Featuring 16 non-floating inputs with RTD (Resistance Temperature Detector) support, this module ensures precise and reliable measurement of temperature and other analog variables, enhancing the overall system performance.

Key Features of the Siemens 6ES5465-4UA11 Analog Input Module

16 Non-Floating Inputs: The 6ES5465-4UA11 provides 16 high-precision analog inputs, supporting a wide range of industrial applications.
RTD Compatibility: This module supports RTD sensors, allowing for accurate temperature measurement in various systems.
Enhanced Accuracy: The analog-to-digital conversion technology ensures that all signals are processed with minimal distortion and high accuracy.
Compact Design: With its space-saving design, the module fits easily into compact control cabinets and panels.
Reliability: Built for tough industrial environments, this module guarantees long-lasting performance and minimizes system downtime.

Technical Specifications

Specification	Details
Model	6ES5465-4UA11
Type	Analog Input Module
Number of Inputs	16
Input Type	Non-floating, RTD
Input Range	-200°C to +850°C (RTD)
Resolution	12 bits
Accuracy	±0.1% of the full scale
Supply Voltage	24 V DC
Current Consumption	120 mA
Mounting Type	DIN rail mounting
Dimensions (L x W x H)	150 x 100 x 50 mm
Weight	0.2 kg
Operating Temperature Range	-20°C to +60°C
Storage Temperature Range	-40°C to +70°C

Advantages of the Siemens 6ES5465-4UA11 Analog Input Module

Wide Input Range: The 6ES5465-4UA11 supports both low and high temperature measurements with an input range of -200°C to +850°C.
High Accuracy: The 12-bit resolution ensures precise analog signal processing, enhancing system performance.
RTD Support: This module is compatible with RTD sensors, offering reliable temperature measurements for various industrial applications.
Easy Integration: The 6ES5465-4UA11 integrates easily into Siemens automation systems, making it an ideal choice for expanding measurement capabilities.
Durable and Compact: Designed to withstand industrial environments, this module offers a compact form factor for installation in space-constrained environments.

Conclusion

The Siemens 6ES5465-4UA11 Analog Input Module is the perfect solution for accurate and reliable analog signal processing in industrial automation systems. With 16 non-floating inputs and RTD support, it offers flexibility and high precision for temperature and other analog measurements. Its compact design and rugged construction ensure durability in demanding environments, making it an excellent choice for enhancing the functionality of your Siemens control systems.
