Siemens 6ES5464-8MA21 Analog Input Module

The Siemens 6ES5464-8MA21 Analog Input Module is designed to provide precise data acquisition for industrial automation systems. With its advanced features and robust design, this module ensures accurate analog-to-digital signal conversion. It integrates seamlessly with Siemens PLCs, offering high performance for a wide range of automation tasks.

Key Features of the 6ES5464-8MA21 Analog Input Module:

8 High-Precision Inputs: The 6ES5464-8MA21 provides 8 independent analog input channels, allowing for the monitoring of multiple signals simultaneously. This flexibility enhances system control and improves overall efficiency.
Wide Signal Compatibility: It supports various input signals, including voltage (0-10V) and current (4-20mA), ensuring compatibility with a wide range of sensors and devices.
12-Bit Resolution: With a 12-bit resolution, this module offers highly accurate data conversion, ensuring precise signal processing and control.
Durable Design: Built to withstand tough industrial environments, the 6ES5464-8MA21 delivers stable performance in a variety of applications.
Easy Integration: It integrates effortlessly with Siemens PLCs, making system installation and setup straightforward.

Specifications:

Feature	Specification
Model	6ES5464-8MA21
Type	Analog Input Module
Number of Inputs	8 analog inputs
Input Signal	Voltage (0-10V), Current (4-20mA)
Input Range	±10V, 0-20mA
Resolution	12-bit
Power Supply	24V DC
Dimensions	125 x 100 x 75 mm
Weight	0.45 kg
Mounting	DIN rail mountable
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Protection Rating	IP20

Benefits:

Efficient Data Acquisition: The 6ES5464-8MA21 ensures high-speed and accurate signal conversion. As a result, the system achieves better control and improved operational efficiency.
Wide Compatibility: This module supports both voltage and current input signals. Therefore, it works seamlessly with a variety of industrial sensors, offering flexibility in diverse applications.
Rugged and Reliable: Designed for tough industrial environments, the 6ES5464-8MA21 guarantees durability and stable performance over time.
Quick Integration: Thanks to its compatibility with Siemens PLCs, this module simplifies system integration, minimizing installation time and cost.

Applications:

The Siemens 6ES5464-8MA21 Analog Input Module is ideal for various industrial applications. It is commonly used in:

PLC Systems: Ensures accurate data input for Siemens PLC systems, optimizing control and monitoring processes.
Process Control: Perfect for acquiring analog signals from sensors used in temperature, pressure, or flow control systems.
Energy Management: The module can efficiently collect data for energy monitoring systems, helping optimize energy consumption.
Machine Monitoring: Ideal for applications where continuous monitoring of industrial equipment is necessary to ensure smooth operation.

By incorporating the 6ES5464-8MA21, industries can enhance their automation systems, improving precision and system reliability.

Conclusion:

In summary, the Siemens 6ES5464-8MA21 Analog Input Module delivers accurate signal conversion for industrial automation systems. With its wide compatibility, high resolution, and durable design, it ensures reliable and precise data acquisition. Whether for process control, energy management, or machine monitoring, this module helps improve system efficiency and performance.
