Siemens 6ES5393-0UA14 Membrane Switch

This membrane switch provides a sealed keypad for SIMATIC S5 operator panels. It gives users a reliable way to enter commands and acknowledge alarms. You can mount this switch directly onto the front panel cutout.

Technical Specifications

Parameter	Details
Brand	Siemens
Model	Siemens 6ES5393-0UA14
Category	Membrane Switch (SIMATIC S5 Series)
Dimensions (H x W x D)	84 mm x 84 mm x 12 mm
Weight	0.08 kg
Number of Keys	14 keys (function + numeric)
Key Arrangement	3 rows x 4 columns + 2 dedicated function keys
Switch Type	Polydome tactile membrane
Actuation Force	250 g ± 50 g per key
Key Travel	0.8 mm typical
Electrical Life	1 million actuations per key
Internal Components	1 polyester overlay + 1 conductive silver circuit layer
Interface Type	14-pin ribbon cable with female connector
Cable Length	250 mm (approx.)
Contact Resistance	< 100 Ω per key
Insulation Resistance	> 10 MΩ at 100 V DC
Operating Voltage	24 V DC (maximum)
Current Rating	10 mA per contact (maximum)
Built-in Energy Storage	None (passive device)
Protection Rating	IP54 (front face)
Operating Temperature	0°C to 50°C

Detailed Feature Overview

This membrane switch includes 14 tactile keys for user input. Each key requires 250 g of force with 0.8 mm travel. Consequently, operators receive clear tactile feedback for every press.

The sealed polyester overlay prevents dust and moisture ingress. An IP54 rating protects the front face from splashing water. The silver conductive circuit layer provides reliable electrical contact over time.

You will find a 14-pin ribbon cable extending from the rear. This cable connects directly to the S5 operator panel board. The 250 mm length gives you flexibility during panel assembly.

Installation and Compatibility

Siemens 6ES5393-0UA14 fits standard S5 operator panel cutouts. Clean the mounting surface thoroughly before attaching the membrane. Plug the ribbon cable into the matching panel connector carefully.
