The Siemens 6ES5210-1AN11 serves as a mounting backbone for your PLC system. This rack belongs to the SIMATIC S5 product family. It holds multiple I/O and function modules in a single chassis. You can use it to build scalable automation solutions.
Key Technical Specifications
Below you will find the accurate technical parameters for the Siemens 6ES5210-1AN11.
| Parameter | Specification |
|---|---|
| Product Type | Rack / Mounting Frame |
| Series | SIMATIC S5 |
| Number of Slots | 10 |
| Backplane Type | Passive bus |
| Operating Voltage | From power supply module |
| Mounting | Screw fix (panel or cabinet) |
| Cooling | Natural convection |
| Manufacturer | Siemens |
The rack measures 483 mm in width and 245 mm in depth. Its total height reaches 160 mm. The Siemens 6ES5210-1AN11 weighs approximately 3.8 kg. This unit contains a passive backplane PCB with ten connectors. Energy storage does not apply to this passive component.
You will find mounting holes on the top and bottom edges. The backplane provides bus connections for all inserted modules. Consequently, modules can communicate without extra wiring. The rack also includes a grounding terminal for safety.
Installation and System Integration
You can mount the Siemens 6ES5210-1AN11 inside any standard 19-inch cabinet. The rack requires a separate power supply module in the first slot. Therefore, you need to choose a compatible PSU for your system. The passive design generates no heat on its own.
