Siemens 6ES5095-8MA04 Compact Unit for SIMATIC S5

The Siemens 6ES5095-8MA04 delivers a space-saving control solution. This compact unit belongs to the SIMATIC S5 family. It combines multiple functions into a single housing. You can use it for small to medium automation tasks.

Key Technical Specifications

Below you will find the accurate technical parameters for the Siemens 6ES5095-8MA04.

The unit measures 265 mm in width and 75 mm in height. Its total depth reaches 130 mm. The Siemens 6ES5095-8MA04 weighs approximately 1.2 kg. This compact unit contains a single main PCB assembly. Energy storage uses onboard capacitors for brief power hold-up.

You will find terminal blocks on the bottom side of the housing. These blocks accept wires from 0.5 to 2.5 mm². The front panel includes LED status indicators for each channel. Consequently, you can diagnose system faults very quickly.

Installation and System Integration

You can mount the Siemens 6ES5095-8MA04 on standard DIN rails. Alternatively, you can screw it directly onto a backplate. The unit draws power from an external 24V DC supply. It does not require a separate expansion rack at all. Therefore, this compact unit suits small control cabinets perfectly.
