Siemens 6DD1607-0AA2 FM458-1 DP Module

Overview

The Siemens 6DD1607-0AA2 belongs to the SIMATIC S7-400 series and functions as an FM458-1 DP application module. It offers advanced data processing performance and supports direct PROFIBUS DP communication. Designed for high-precision control systems, this module integrates efficiently with automation networks and ensures fast and reliable signal transmission.

Its robust structure and precise timing features make it ideal for complex automation tasks in industries such as manufacturing, energy, and process control.

Technical Specifications

Parameter	Description
Brand	Siemens
Model	6DD1607-0AA2
Series	SIMATIC S7-400
Type	FM458-1 DP Application Module
Supply Voltage (DC)	5 V DC and 24 V DC
Voltage Range	4.8 V to 5.25 V (including ripple)
Current Consumption (Typical)	1.5 A
Current Consumption (Max)	3 A
Memory Type	SRAM Backup
Backup Current (Max)	15 µA
Real-Time Clock	Hardware-based, 500 ms resolution
Digital Inputs	8 channels (Connector X2)
Input Voltage (DC)	Rated at 24 V
Signal “0” Range	-1 to +6 V
Signal “1” Range	13.5 to 33 V
Input Current (Signal “1”)	Typical 3 mA at 24 V
Input Delay (0 → 1)	Max. 5 µs
PROFIBUS DP Services	Equidistance and Slave-to-Slave Communication
Alarm Functions	Supported
Potential Separation	Optional via interface module
Compliance	RoHS, WEEE, REACH

Environmental and Compliance

The 6DD1607-0AA2 meets RoHS and WEEE environmental directives and fulfills REACH Article 33 reporting requirements. The product contains traceable substances such as lead and silicic acid compounds as listed under SCIP number 12b00e97-b2ca-4960-9769-f4184c4a53b0.

This model ensures reliable long-term performance and easy recycling compliance in industrial automation environments.

Physical Characteristics

Parameter	Value
Dimensions (L × W × H)	30.20 × 23.30 × 4.00 cm
Net Weight	1.162 kg
Packaging Quantity	1 Piece
Dangerous Goods Classification	No
Country of Origin	Germany

Performance and Reliability

The Siemens 6DD1607-0AA2 supports high-speed data handling, real-time synchronization, and advanced control logic for demanding automation systems. It efficiently processes complex tasks through its fast input response and dependable data storage. With direct PROFIBUS DP connectivity and flexible voltage compatibility, this module enhances system scalability and integration.

Its German engineering ensures durability, consistent operation, and minimal maintenance across diverse industrial applications.

Key Features

Dual supply voltage for flexible integration (5 V and 24 V DC).
Eight isolated digital input channels for precise signal control.
Fast 5 µs input response time for high-performance automation.
Built-in SRAM backup with low current consumption (15 µA).
Hardware clock for reliable real-time operations.
Full PROFIBUS DP support, including equidistance and slave communication.
Compact 1.162 kg design with easy installation.

Applications

The Siemens 6DD1607-0AA2 FM458-1 DP is widely used in:

Distributed automation systems
Process control and data acquisition
Energy and power plant automation
Industrial machinery control

Lifecycle & Availability

This model is listed as Prod. Cancellation, but remains available through Siemens stock and authorized distributors for replacement or retrofit projects.

Country of Origin: Germany
Manufacturer: Siemens AG
Product Family: SIMATIC S7-400
