Siemens 6AV6541-0AA05-2BE0 Operator Panel

Intuitive HMI Interface for SIMATIC Systems

The Siemens 6AV6541-0AA05-2BE0 functions as a versatile operator panel within the SIMATIC HMI family. This panel features a 5.7-inch STN color display with a resolution of 320 x 240 pixels for clear visual feedback. Its robust housing measures 212 mm in height, 156 mm in width, and 46 mm in depth, fitting standard cutouts. The total weight reaches approximately 0.9 kg, making it suitable for both machine and cabinet mounting.

This operator panel includes 24 function keys with tactile feedback for efficient operator interaction. The following table details the complete technical specifications for this HMI solution:

Parameter	Specification
Product Brand	Siemens
Product Model	6AV6541-0AA05-2BE0
Product Category	Operator Panel
Platform Compatibility	SIMATIC S5, S7, and third-party
Display Size	5.7 inches
Display Type	STN color
Resolution	320 x 240 pixels
Backlight	CCFL with 50,000 hours lifespan
Function Keys	24 (tactile)
Communication Ports	RS-232, RS-485, TTY
Memory	1 MB user memory
Dimensions (H x W x D)	212 mm x 156 mm x 46 mm
Weight	0.9 kg
Supply Voltage	24 V DC
Power Consumption	12 W typical
Operating Temperature	0°C to +50°C
Storage Temperature	-20°C to +60°C
Protection Rating	IP65 (front panel)

Display Performance and Visual Clarity

The 5.7-inch STN color display provides clear visual representation of process data and alarm messages. CCFL backlight technology delivers uniform brightness with an operational lifespan of 50,000 hours. This longevity ensures consistent display quality over years of continuous operation. Users can therefore rely on the panel for long-term deployment without frequent maintenance.

Operator Interface and Keypad Configuration

Twenty-four function keys offer programmable operation for navigation, parameter entry, and direct commands. Tactile feedback gives operators confident keystroke confirmation even when wearing industrial gloves. The panel supports both numeric and alphanumeric data entry through integrated soft keys. This flexibility accommodates diverse operator interaction needs across different applications.

Communication and System Integration

The 6AV6541-0AA05-2BE0 supports RS-232, RS-485, and TTY communication protocols for flexible connectivity. This panel interfaces seamlessly with SIMATIC S5 and S7 controllers as well as third-party PLCs. One megabyte of user memory stores screens, alarms, and recipes for standalone operation. Engineers can therefore deploy this panel in both new installations and legacy system upgrades.
