Siemens 6AV3572-2FM00 Display Panel

The 6AV3572-2FM00 serves as a display panel for Siemens automation systems. This HMI terminal provides touchscreen control and process visualization. Its rectangular frame measures 285 millimeters in width. The panel height reaches 212 millimeters exactly. Depth stays at 55 millimeters. You will find this unit weighs approximately 1.85 kilograms. Therefore, installation requires cutting a panel opening and securing with clamps. One front-panel USB port supports data transfer and screen backups.

Physical Layout and Connectors

The front panel features a 10.4-inch color TFT touchscreen display. You will find eight programmable function keys below the screen. One RS-232 serial port connects to PLC programming software. A second RS-485 port supports MPI or Profibus communication. Four status LEDs indicate power, communication, and system status.

Technical Specifications

Parameter	Specification
Panel Width	285 mm
Panel Height	212 mm
Panel Depth	55 mm
Unit Weight	1.85 kg
Display Size	10.4 inches diagonal
Display Type	TFT LCD, 256K colors
Resolution	640 x 480 pixels (VGA)
Touchscreen	Analog resistive
Function Keys	8 programmable
Communication Ports	RS-232, RS-485, USB
Component Total	486 discrete parts
Internal Energy Storage	1500 µF capacitor bank
Backlight Type	CCFL (replaceable)
Backlight Life	50,000 hours typical
Operating Temperature	0°C to +45°C

Internal Design and Energy Storage

The 6AV3572-2FM00 contains exactly 486 discrete components inside. A 1500 microfarad capacitor bank filters noise from the 24V DC power input. A 32-bit processor manages display graphics and communication tasks. The unit includes flash memory for storing screen configuration data. A CCFL backlight illuminates the TFT panel evenly. The touchscreen controller digitizes user input with 12-bit resolution.

Operational Performance

This display panel shows process data from Siemens PLCs in real time. It accepts user inputs through touch and function keys. Moreover, the unit supports multiple communication protocols for flexibility. You can upload screen configurations via USB or serial ports. The panel logs alarm messages and operator actions for review. Four LEDs show power, communication, and system status clearly. Consequently, you achieve intuitive machine control and monitoring. Siemens designed this panel for factory floor environments. Its sealed front meets IP65 protection standards.

In summary, the 6AV3572-2FM00 delivers reliable display panel functionality. Use this panel for machine control and process visualization. It provides clear graphical display for operator interaction. Order this display panel for your Siemens automation system.
