The 6AV1132-0DB10 operates as a versatile industrial HMI module for Siemens automation systems. This unit provides a graphical user interface for monitoring and controlling complex processes. It displays machine status, production data, and alarm messages clearly on its screen. The module supports both keypad and touchscreen input methods for flexibility. Consequently, it enhances operator productivity and situational awareness on the factory floor.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Category | HMI Module |
| Part Number | 6AV1132-0DB10 |
| Display Type | TFT LCD (color) |
| Display Size | 15.0 cm (diagonal) |
| Display Resolution | 640 x 480 pixels (VGA) |
| Touchscreen | Resistive (analog) |
| Function Keys | 8 (configurable) |
| Communication | RS-232, RS-422, RS-485, Ethernet |
| Memory | 4 MB (application storage) |
| Power Supply | 24 VDC |
| Current Consumption | 500 mA |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Dimensions | 22.0 cm x 17.0 cm x 6.5 cm |
| Weight | 1.5 kg |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel-mount |
Display and Interaction Features
The 6AV1132-0DB10 features a bright TFT display with VGA resolution for detailed graphics. Users can create dynamic screens with trend charts and data logs. The resistive touchscreen responds to gloved hands and stylus inputs. Additionally, eight configurable function keys provide quick access to key operations. The module supports multi-language text for global deployment.
Communication and Integration
This HMI module supports multiple communication interfaces for flexible integration. It connects to Siemens PLCs and third-party devices seamlessly.
