SCHUNK MPG-plus 40 Gripper | Pneumatic Small Component Actuator

High-Precision SCHUNK MPG-plus 40 Gripper

The SCHUNK MPG-plus 40 gripper ID 305521 is a compact and reliable solution for handling small components. Designed for high accuracy and repeatable performance, it integrates seamlessly into modern automation systems.

Reliable Pneumatic Gripper Performance

This SCHUNK pneumatic gripper offers a 6 mm stroke per jaw and a 135 N closing force. With an operating pressure range of 2–8 bar, it ensures consistent gripping strength across diverse industrial applications.

Compact and Lightweight Design

The MPG-plus 40 gripper weighs only 0.18 kg, making it ideal for lightweight robots and compact automation setups. Despite its small size, it can securely handle workpieces up to 0.7 kg.

Durable and Industrial-Grade Build

Engineered for demanding environments, the SCHUNK MPG-plus gripper ensures reliable operation within an ambient temperature of 5–90 °C. Its repeat accuracy of 0.02 mm guarantees precise and consistent handling.

📊 SCHUNK MPG-plus 40 Technical Specifications

Parameter	Value
Model	SCHUNK MPG-plus 40
Gripper Type	Small Component Pneumatic Gripper
Stroke per jaw	6 mm
Closing force	135 N
Opening force	110 N
Recommended workpiece weight	0.7 kg
Weight	0.18 kg
Cylinder volume (double stroke)	4.1 cm³
Operating pressure	2 – 8 bar
Nominal pressure	6 bar
Closing / Opening time	0.04 s
Repeat accuracy	0.02 mm
Max. finger length	50 mm
Max. finger weight	0.08 kg
Protection class	IP30
Ambient temperature	5 – 90 °C
Dimensions (L × W × H)	40 × 26 × 39 mm
Max. axial force	170 N
Max. torque Mx / My / Mz	1.5 / 2.0 / 4.0 Nm
Cleanroom class	ISO 6
