Schneider XBTF011310 Magelis Keypad Repair

This service restores failed membrane keypad switches on Schneider Magelis operator terminals. It replaces worn contact layers and conductive traces on the XBTF series panels. Therefore, it extends the service life of industrial HMI equipment without full replacement.

Technical Specifications of Schneider XBTF011310 Membrane Keypad

The Schneider XBTF011310 membrane keypad measures 18.0 cm in length and 12.0 cm in width. Its keypad weight equals approximately 0.12 kg for easy handling. A single 14-pin flat ribbon cable connects the keypad to the HMI controller board. Additionally, the keypad contains 22 programmable function keys.

Parameter	Specification
Brand	Schneider Electric
Full Model	XBTF011310
Category	Magelis Membrane Keypad Switch (Repair/Replacement)
Dimensions (L x W)	18.0 cm x 12.0 cm (7.09″ x 4.72″)
Keypad Thickness	1.2 mm (0.047 inches)
Keypad Weight	0.12 kg (0.26 lbs)
Interface Connector	1 x 14-pin Flat Ribbon Cable (0.1″ Pitch)
Cable Length	10 cm (3.94 inches) from Keypad to Connector
Number of Keys	22 Programmable Function Keys
Key Layout	5 Rows x 4 Columns + 2 Dedicated Keys
Key Type	Dome Switch (Tactile Feedback)
Actuation Force	180 to 250 grams per Key
Switch Travel	0.5 mm to 0.8 mm
Contact Resistance	< 100 Ohms (New or Repaired)
Insulation Resistance	> 100 Megaohms (Between Traces)
Maximum Voltage Rating	24 VDC
Maximum Current Rating	10 mA per Switch
Operating Life	1 Million Actuations per Key (Minimum)
On-Board Components	22 Metal Dome Switches + 2 Conductive Silver Traces + 1 Polyester Overlay + 1 Adhesive Backing
Energy Storage	None (Passive Membrane Switch)
Operating Temperature	0°C to +50°C (32°F to 122°F)
Storage Temperature	-20°C to +60°C (-4°F to 140°F)
Environmental Protection	IP54 (Front Surface Only)
Repair Service	Trace Restoration + Dome Replacement + Cleaning

Repair Process and Keypad Restoration

The Schneider XBTF011310 repair service addresses multiple failure modes.Consequently, the repaired keypad performs like a new original component.

Common Symptoms and Failure Diagnosis

You will notice non-responsive keys or intermittent button operation on your Magelis panel. Some keys may require excessive force to register a press. Others may remain permanently activated due to trace short circuits. Our repair service resolves all these common XBTF series issues reliably.

Installation After Repair

The repaired keypad includes fresh adhesive backing for secure panel attachment. You simply remove the protective liner and press the keypad into place. Then connect the 14-pin ribbon cable to the HMI controller board. Thus, your Magelis terminal returns to normal operation quickly.
