Schneider TSXP57202M Processor Module

The TSXP57202M serves as a reliable processor core for Modicon Premium automation platforms. This Schneider Electric unit executes control logic with consistent performance for mid-range applications. We engineered this module to balance processing power with cost-effective system design.

Technical Specifications and Design Features

This processor module weighs approximately 0.52 kilograms. Its dimensions measure 130 millimeters in height, 70 millimeters in width, and 140 millimeters in depth. The unit features a durable plastic housing with integrated heat dissipation channels.

Parameter	Specification
Manufacturer	Schneider Electric
Model	TSXP57202M
Category	Processor Module
Product Line	Modicon Premium
Processor Type	32-bit RISC
Memory	768 KB RAM, 384 KB Flash
Processing Speed	0.18 µs per instruction
I/O Capacity	1024 digital, 128 analog
Programming Software	PL7 Pro, Unity Pro
Communication Ports	1 x Modbus RS-485
Backup Battery	Lithium 3V (integrated)
Operating Temperature	0°C to 60°C
Dimensions (H x W x D)	130 mm x 70 mm x 140 mm
Weight	0.52 kg

Engineers will value the balanced memory configuration within the TSXP57202M. This processor provides 768 kilobytes of RAM for program execution and data storage. An additional 384 kilobytes of flash memory securely stores applications during power cycles.

Furthermore, the single Modbus RS-485 port enables straightforward connectivity. This port supports communication with operator terminals, drives, and field devices. Consequently, the TSXP57202M integrates easily into existing Modicon architectures.

Energy Storage and Data Integrity

The TSXP57202M includes a lithium 3V backup battery for critical data preservation. This battery maintains program integrity and real-time clock accuracy during power interruptions. Engineers can trust this energy storage to protect valuable application data in the field.

Programming Environment and System Integration

You can program this processor using either PL7 Pro or Unity Pro software. The TSXP57202M supports multiple IEC 61131-3 programming languages. This flexibility allows developers to choose the most suitable approach for each control task.

The processor manages up to 1024 digital I/O points and 128 analog channels. This capacity makes it ideal for mid-sized automation projects across manufacturing and processing industries. For reference, other Modicon Premium components share this same backplane architecture with the TSXP57202M.

Performance Metrics and Operational Reliability

This unit executes instructions in just 0.18 microseconds per operation. Consequently, it handles fast logic scanning and time-critical processes with reliable precision. The TSXP57202M includes diagnostic LEDs for power, run, and communication status. These indicators provide immediate feedback during system startup and troubleshooting.
