Schneider TSXMFPP004M Flash EPROM Memory Module

Overview

The Schneider TSXMFPP004M is a high-performance Flash EPROM memory module in the Modicon series, providing efficient data storage and handling. With a capacity of 4096 kB, it supports substantial data storage needs for automation applications.

Key Features

Memory Type: Utilizes Flash EPROM technology to provide fast and reliable data storage.
Memory Capacity: Offers 4096 kB of memory, making it suitable for various industrial applications.
Slot Compatibility: Specifically designed for installation in Slot 0, ensuring stable and secure integration.
Compact and Lightweight: Weighing only 0.044 kg, it is easy to install and manage in industrial systems.
Operating Conditions: Designed to work efficiently in environments with temperatures ranging from 0°C to 60°C.
Humidity Resistance: Accommodates 80% non-condensing humidity, ensuring stable performance in humid conditions.
Altitude Compatibility: The module operates effectively at altitudes up to 1000 meters.
Protection: With an IP20 protection rating, it protects against solid objects larger than 12.5 mm.
Compliance: Meets CE standards, ensuring high safety and reliability.

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Product Line	Modicon
Part Number	TSXMFPP004M
EAN	3595862065351
Memory Type	Flash EPROM
Memory Capacity	4096 kB
Slot Compatibility	Slot 0
Maximum Operating Temperature	60°C
Minimum Operating Temperature	0°C
Operating Humidity	80% (non-condensing)
Storage Humidity	80% (non-condensing)
Maximum Operating Altitude	1000 meters above sea level
Protection Class	IP20
Standards	CE
Weight	0.044 kg

Performance & Durability

The TSXMFPP004M module performs well in demanding environments, supporting high temperatures of up to 60°C. It operates reliably in humid conditions with up to 80% non-condensing humidity. Additionally, it can function at altitudes of up to 1000 meters, making it adaptable for various installation scenarios.

Its IP20 protection ensures the module is safe from solid particles larger than 12.5 mm, adding an extra layer of durability for industrial settings.

Installation and Usage

Designed for installation in Slot 0, the TSXMFPP004M is compatible with Modicon systems, offering simple and secure integration. Its compact weight of 0.044 kg ensures easy handling and installation in control panels and industrial setups.

Conclusion

The Schneider TSXMFPP004M memory module provides a reliable solution for data storage in Modicon systems. With 4096 kB memory capacity, IP20 protection, and operational efficiency across a wide range of conditions, it is an essential component for industrial automation systems.
