Schneider TSXDEZ12D2K Discrete Input Module for Modicon Premium

Technical Overview of This Digital Input Device

The Schneider TSXDEZ12D2K captures field signals for your control system. This discrete input module belongs to the Modicon Premium TSX series from Schneider Electric. It reads twelve digital signals from sensors and switches. Consequently, your PLC receives accurate status information for decision making.

Hardware Specifications and Design Details

This input module weighs approximately 0.25 kg. Its compact dimensions are 130 mm in height, 40 mm in width, and 140 mm in depth. The Schneider TSXDEZ12D2K features twelve discrete input channels. A removable screw terminal block provides easy wiring access. The module stores no internal energy after power removal. Therefore, it does not retain any signal data without external power.

Installation and Connection Guidelines

You can install the Schneider TSXDEZ12D2K directly into a Premium rack. It connects to sensors through the removable terminal block. Furthermore, each channel features an individual LED indicator. This design allows quick visual status checking for troubleshooting. Always use shielded cables for noisy industrial environments. This practice prevents false triggering from electrical interference.
