Schneider TSX3722AC | Robust PLC | Modicon Premium Controller

The Schneider TSX3722AC delivers reliable control for demanding industrial automation environments. This robust PLC features a built-in power supply for simplified system integration. It supports 256 discrete I/O and 32 analog I/O channels for medium-scale applications. Weighing only 1.2 kg, the Schneider TSX3722AC mounts directly into a Premium rack. Its dimensions measure 187.9 mm x 151.5 mm x 160 mm.

Processing Power and Memory Architecture

The Schneider TSX3722AC executes 70 instructions per millisecond for efficient real-time control. This controller includes 128 KB of flash memory for program and data storage. It also features 32 KB of internal RAM for fast variable access. Moreover, the Schneider TSX3722AC supports up to 4 communication modules for network expansion. Consequently, you can build distributed control systems with multiple remote I/O drops.

Built-in Communication and Energy Storage

The Schneider TSX3722AC features a built-in multi-standard serial port for programming. This port supports Modbus, Uni-Telway, and character mode protocols for flexible connectivity. The controller also includes a Mini DIN connector for terminal or HMI connections. Importantly, the Schneider TSX3722AC contains a lithium battery for SRAM data backup. This battery provides energy storage for up to 1,000 hours without external power. Therefore, your program remains safe during extended power outages.

Technical Specifications Table

Below are the complete technical parameters for engineers and procurement teams:

Parameter	Specification
Full Product Name	Schneider TSX3722AC
Product Category	Modicon Premium Robust PLC
Processor Type	16-bit microcontroller
Processing Speed	70 instructions per millisecond
Program Memory (Flash)	128 KB
Internal RAM	32 KB
Discrete I/O Capacity	Up to 256 channels
Analog I/O Capacity	Up to 32 channels
Built-in Power Supply	24 V DC or 100-240 V AC
Power Supply Output	5 V DC, 1.5 A for backplane
Built-in Communication Ports	1 x multi-standard serial (RS232/RS485)
Serial Port Connector	Mini DIN (5-pin)
Supported Protocols	Modbus, Uni-Telway, Character mode
Maximum Communication Modules	4
Maximum Ethernet Modules	2
Energy Storage Type	Lithium battery (user-replaceable)
Battery Backup Duration	1,000 hours (approximately 41 days)
Current Consumption (Backplane)	Supplies power to rack modules
Number of Components	1 main PCB + power supply unit + battery holder + metal housing
Net Weight	1.2 kg (1,200 grams)
Gross Weight (packaged)	1.5 kg
Dimensions (H x W x D)	187.9 mm x 151.5 mm x 160 mm
Real-Time Clock Accuracy	±5 minutes per month
RTC Battery Backup	Same lithium battery (shared)
Operating Temperature	0°C to +60°C
Storage Temperature	-25°C to +85°C
Vibration Resistance	3.5 mm at 2 to 9 Hz, 1 gn at 9 to 150 Hz
Shock Resistance	15 gn for 11 ms
Degree of Protection	IP20
Certifications	CE, UL 508, CSA, ATEX Zone 2, Marine (BV, DNV, GL, LROS)
Configuration Software	PL7 Pro (version 4.3 or higher)

Installation and Application Details

The Schneider TSX3722AC mounts directly into the leftmost slot of any Premium rack. This controller includes its own power supply, so it needs no external power module. You need PL7 Pro software version 4.3 or higher for programming. The Schneider TSX3722AC suits harsh environments like metalworking, mining, and outdoor installations. Its robust design withstands high vibration and shock levels. Thus, this controller delivers dependable performance where standard PLCs often fail. Replace the lithium battery every 5 years under normal operating conditions.
