Schneider TSX372200 Analog Input Module

The Schneider TSX372200 is an advanced analog input module specifically engineered for high-performance industrial automation applications. Designed for the Modicon series, it ensures precise and reliable measurements for analog signals. Whether used in control systems, monitoring, or data acquisition, this module delivers excellent accuracy, making it the ideal choice for a variety of applications.

Key Features and Specifications

Feature	Specification
Model	Schneider TSX372200
Product Type	Analog Input Module
Series	Modicon
Number of Channels	8 Channels
Input Voltage Range	-10V to 10V
Resolution	12 bits
Input Impedance	> 1 MΩ
Sampling Rate	10 ms
Input Types	Differential or Single-ended
Power Consumption	< 3 W
Mounting Type	DIN Rail
Dimensions (W x H x D)	90 x 75 x 60 mm
Weight	0.35 kg (0.77 lbs)
Operating Temperature	0°C to 60°C
Relative Humidity	5% to 95% (non-condensing)
Standards	CE, UL

Accurate and Efficient Analog Signal Measurement

With 8 input channels, the Schneider TSX372200 handles a wide range of analog signals, from -10V to 10V, offering versatile performance. The 12-bit resolution ensures that the measurements are highly accurate, which is critical for precise monitoring and control applications. Additionally, its efficient signal processing enables fast response times, maintaining optimal system performance.

Easy Integration and Flexible Configuration

This module seamlessly integrates into control panels with its DIN rail mounting system, simplifying installation. The Schneider TSX372200 supports both differential and single-ended input types, allowing it to meet various sensor requirements. Furthermore, its compact dimensions of 90 x 75 x 60 mm ensure it can fit into tight spaces while providing full functionality.

Built for Robust Industrial Environments

The Schneider TSX372200 operates reliably in industrial settings, with an operating temperature range of 0°C to 60°C. It is compliant with CE and UL standards, ensuring that it meets safety and quality regulations. With < 3 W power consumption, this module is also energy-efficient, contributing to lower operational costs over time.
