Schneider TSX1724012 CPU Controller

The TSX1724012 serves as a compact CPU controller for Schneider automation systems. This unit executes logic programs and manages I/O operations efficiently. Its rectangular frame measures 100 millimeters in width. The controller height reaches 90 millimeters exactly. Depth stays at 75 millimeters. You will find this unit weighs approximately 0.42 kilograms. Therefore, installation requires a standard DIN rail clip mounted securely. One removable terminal block provides power input connections.

Physical Layout and Connectors

The front panel features a 2-line LCD display for diagnostic messages. You will find four push buttons for local configuration access. One RS-232 serial port connects to programming software. Four status LEDs indicate run, stop, error, and power conditions. Four mounting tabs secure the unit to TS35 DIN rails.

Technical Specifications

Parameter	Specification
Controller Width	100 mm
Controller Height	90 mm
Controller Depth	75 mm
Unit Weight	0.42 kg
Processor	16-bit @ 12 MHz
Program Memory	32 KB
Data Memory	16 KB (retentive)
Scan Time	1.5 ms per 1K instructions
Digital I/O	12 (6 inputs, 6 outputs)
Communication Port	RS-232 (programming)
Component Total	286 discrete parts
Internal Energy Storage	470 µF capacitor bank
Backup Battery	Lithium (3V, 5 years)
Operating Temperature	0°C to +55°C

Internal Design and Energy Storage

The TSX1724012 contains exactly 286 discrete components inside. A 470 microfarad capacitor bank filters the main power supply input. This bank holds enough charge for 20 milliseconds after power loss. The 16-bit processor runs at 12 megahertz for reliable execution. A lithium battery retains data memory for up to five years. EEPROM stores the user program without any battery backup required.

Operational Performance

This CPU controller executes logic from 32 kilobytes of program memory. It scans 1,000 instructions in approximately 1.5 milliseconds. Moreover, the unit includes 12 onboard digital I/O points for basic control. You can connect sensors, pushbuttons, and small actuators directly. The LCD display shows real-time system status and diagnostic messages. Four buttons let you navigate menus without a programming computer. Consequently, you achieve compact control for small automation projects. Schneider designed this controller for standalone machine applications. Its industrial enclosure meets IP20 protection standards.

In summary, the TSX1724012 delivers reliable CPU controller performance. Use this unit for small conveyors or packaging stations. It reduces system cost with integrated I/O points. Order this CPU controller for your Schneider automation project.
