Schneider TM2DRA16RT Digital Output Module

Technical Overview of the Schneider Electric Output Device

The Schneider TM2DRA16RT expands your control system with sixteen digital outputs. This module belongs to the Modicon TM2 range for PLCs. It provides a robust interface for actuators and relays. Each output channel handles up to 2 amps. Consequently, the total current per common return reaches 8 amps.

Key Specifications and Hardware Details

This module weighs approximately 0.2 kg. Its compact dimensions are 90 mm in height, 23.6 mm in width, and 70 mm in depth. The TM2DRA16RT uses a removable screw terminal block for wiring. This design simplifies maintenance and replacement tasks. The device stores no internal energy after power loss. Instead, it relies on external protective circuits.

Parameter	Specification
Manufacturer	Schneider Electric
Product Series	Modicon TM2
Output Type	Relay, 16 channels (8 x 2 groups)
Output Voltage	24 V DC to 240 V AC
Output Current	2 A per channel (resistive)
Common Return Current	8 A max per group
Response Time	≤ 10 ms (off to on) / ≤ 10 ms (on to off)
Isolation	1500 V RMS between channels and bus
Dimensions (H x W x D)	90 x 23.6 x 70 mm
Net Weight	0.2 kg (0.44 lbs)
Wiring	Removable screw terminal block
Energy Storage	None (no internal backup capacitor)

Installation and Integration Notes

You can mount this digital output module on a DIN rail. It connects directly to a Modicon M221 or M241 controller. Furthermore, the device supports mixed AC/DC loads without additional adapters. Always use an external fast-acting fuse for each group. This practice protects the relay contacts from short circuits.
