Schneider MMPMD24T0C Modicon PanelMate

The MMPMD24T0C serves as a robust operator interface for Modicon automation systems. This Schneider Electric PanelMate unit combines a color LCD with touch screen functionality. We engineered this interface to withstand demanding industrial environments while providing clear visualization.

Technical Specifications and Design Features

This interface panel weighs approximately 6.97 kilograms. Its dimensions measure 280 millimeters in height, 350 millimeters in width, and 70 millimeters in depth. The unit features an industrial-grade housing that resists dust and moisture ingress.

Parameter	Specification
Manufacturer	Schneider Electric
Model	MMPMD24T0C
Category	Interface PanelMate / Operator Terminal
Product Line	Modicon
Display Type	10-inch Color LCD (Dual Scan)
Resolution	800 x 600 pixels
Input Power	24V DC
Operating Temperature	0°C to 50°C
Interface Type	Dual communication connectors
Keypad Type	Keypad with integrated color touch screen
Mounting Type	Panel mount
Dimensions (H x W x D)	280 mm x 350 mm x 70 mm
Weight	6.97 kg (15.38 lbs)

Engineers will appreciate the dual-input power design of the MMPMD24T0C. The unit accepts 24V DC through either of its two connectors. This redundancy ensures continuous operation even if one power source experiences interruption.

Furthermore, the display technology prioritizes visibility in industrial lighting conditions. The dual-scan color LCD delivers crisp graphics at 800 x 600 resolution. Users can interact through both the physical keypad and the responsive touch screen interface.

Connectivity and Installation

You can mount this interface directly into standard industrial panels. The MMPMD24T0C requires a panel cutout with precise dimensions for flush installation. Two communication connectors provide flexible connectivity to Modicon controllers and other automation devices.

The interface supports multiple protocols for seamless integration into existing architectures. Operators can monitor processes, acknowledge alarms, and modify parameters through the intuitive interface. For reference, other Modicon operator terminals share this same rugged design philosophy.

Durability and Operating Environment

This unit operates reliably across a temperature range from 0°C to 50°C. The industrial-grade construction withstands vibration and minor impacts common in manufacturing facilities. The MMPMD24T0C includes protective sealing around the display bezel. This sealing prevents debris from entering behind the panel surface.
