Schneider MA-0329-001 F Connector

The Schneider MA-0329-001 is a high-performance connectivity solution designed for the Modicon Quantum series. This F connector is engineered with robust metal construction, providing a secure and reliable connection for RG-6 coaxial cables in demanding industrial environments. Whether you’re integrating into new systems or upgrading existing ones, this connector offers dependable performance and durability.

Key Features of the Schneider MA-0329-001

Durable Metal Construction: The features a rugged metal build, ensuring long-lasting reliability and strength in diverse applications.
Wide Temperature Range: Operates effectively between 0°C to 60°C and can withstand extreme storage conditions from -40°C to 85°C.
High Altitude Capability: The connector remains reliable even at altitudes of up to 5000 meters, making it suitable for various industrial locations.
Moisture Resistance: It functions optimally in environments with up to 95% relative humidity without condensation.
Electrostatic and Electromagnetic Protection: The MA-0329-001 offers 4 kV contact and 8 kV air electrostatic discharge (ESD) resistance, as well as protection against electromagnetic fields up to 10 V/m.
Sustainability Compliant: This product is mercury-free and complies with EU RoHS, China RoHS, and WEEE regulations, making it an eco-friendly choice for your automation systems.

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Product Line	Modicon Quantum
Part Number	MA-0329-001
EAN	3595862372671
Weight	0.19 lbs (0.09 kg)
Connector Type	F connector, robust metal construction
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Relative Humidity	Up to 95% without condensation
Altitude	Up to 5000 meters
Compatibility	Compatible with RG-6 coaxial cables
Electrostatic Discharge Resistance	4 kV contact, 8 kV air (IEC 801-2)
Electromagnetic Field Resistance	10 V/m (80-2000 MHz, IEC 801-3)
Mercury-Free	Yes
Sustainability	Green Premium, EU RoHS, China RoHS, WEEE compliant
Installation	Easy, straightforward setup

Application and Usage

The Schneider MA-0329-001 connector is perfect for use in industrial automation systems, particularly when working with RG-6 coaxial cables. It is designed for the Modicon Quantum series and offers reliable, high-performance connectivity for various applications. Its durable build and wide environmental tolerance make it suitable for challenging conditions, including high altitudes, extreme temperatures, and humid environments.
