Schneider KOS 882 Electrical Board

The Schneider KOS 882 provides centralized power distribution and control for industrial automation systems. This electrical board belongs to the KOS series for reliable panel building applications. Engineers will appreciate its modular design and comprehensive protection features.

Technical Specifications & Physical Characteristics

This electrical board features a pre-configured enclosure with integrated DIN rails and wiring channels. The KOS 882 includes four mounting rows capable of accommodating up to 36 modular devices. Each row provides 225 mm of usable rail space for circuit breakers, contactors, and power supplies.

Specifically, the enclosure measures approximately 800 mm in height, 600 mm in width, and 250 mm in depth. Its total weight reaches roughly 18.5 kg, requiring secure wall or floor mounting. Furthermore, this board contains no internal energy storage components beyond installed devices.

Parameter	Specification
Manufacturer	Schneider Electric
Model	KOS 882
Type	Electrical Distribution Board
Enclosure Dimensions (H x W x D)	800 mm x 600 mm x 250 mm
Weight	18.5 kg
Mounting Rows	4 rows
Usable Rail Space per Row	225 mm
Modular Device Capacity	36 devices (9 per row)
Ingress Protection	IP40 (standard), IP54 option available
Material	Powder-coated steel
Energy Storage	None (depends on installed components)

Enclosure Design and Configuration

You can install this electrical board in control rooms or industrial environments with minimal preparation. The four mounting rows provide ample space for organizing power and control components. Pre-installed wiring channels simplify cable routing and improve panel aesthetics.

Moreover, the KOS 882 features a hinged front door with a locking mechanism for secure access. The enclosure construction uses powder-coated steel for durability in industrial settings. For similar industrial control components, you can explore the RMS TSG TZ C Static Trip unit series.

Installation and Operational Features

The physical layout of the Schneider KOS 882 facilitates straightforward component mounting and wiring. Technicians will find the DIN rails pre-installed and ready for modular device attachment. The board’s generous dimensions accommodate future expansions or system upgrades.

Furthermore, the unit incorporates no internal energy storage elements beyond user-installed devices. This characteristic simplifies safety procedures during maintenance activities. Consequently, you can modify or service the board without complex discharge protocols.
