Product Overview
The Schneider Harmony XK XKBA15330 joystick controller is part of the Harmony XK range, designed for precise and reliable industrial control. With two movements and four operating directions, it offers smooth operation for light hoisting applications. Its robust construction and long service life make it a trusted choice for demanding environments.
Key Benefits
- Reliable Performance: Withstands up to 1,000,000 mechanical cycles.
- Rugged Design: Metal bezel and collar ensure durability under stress.
- Safety Compliance: Meets UL, CSA, and IEC standards for industrial use.
- Flexible Operation: Supports multiple notches per direction for fine control.
- Wide Compatibility: Works with standard industrial circuits and protection devices.
Applications
The XKBA15330 joystick controller is ideal for:
- Light hoisting equipment
- Industrial cranes and lifts
- Machine control panels
- Material handling systems
- Industrial automation stations
Technical Specifications
General
- Range: Harmony XK
- Type: Complete joystick controller
- Movements: 2
- Directions: 4
- Reference: XKBA15330
Construction
- Bezel: Metal
- Collar: Metal
- Operator profile: Handle with mechanical interlock
Environmental Ratings
- Operating temperature: -20…70 °C
- Storage temperature: -40…70 °C
- Protection rating: IP54 (front), IP20 (terminals)
- Overvoltage category: Class I (IEC 61140)
Electrical Characteristics
- Contact designation: A300, Q300
- Thermal current (Ith): 10 A
- Insulation voltage (Ui): 500 V IEC 60947-1
- Short-circuit protection: 10 A cartridge fuse gG
Mechanical Characteristics
- Mechanical durability: 1,000,000 cycles
- Vibration resistance: 6 gn (IEC 60068-2-6)
- Shock resistance: 20 gn (IEC 60068-2-27)
- Notches per direction: 12°–20°–28°
Connections
- Captive screw clamp terminals
- 2 × 1.5 mm² with cable end
- 1 × 2.5 mm² without cable end
- ≥1 × 0.5 mm²
Certifications and Standards
- UL 508
- CSA C22.2 No 14
- EN/IEC 60947-5-1
- CSA, UL, CCC, RRS
Ordering Information
- Reference: XKBA15330
- GTIN: 785901836988
- Category: US1000I22474
- Returnable: No
- Warranty: 18 months
Why Choose Schneider Harmony XK Joystick Controllers?
Schneider Electric is a global leader in industrial automation. The Harmony XK joystick controller series is engineered for reliability, precision, and compliance with international standards. Choosing the XKBA15330 ensures long-term operational safety, reduced downtime, and smooth control for hoisting and industrial automation projects.
