Schneider Electric PCE984265C – Compact CPU Module for Automation Control

The Schneider Electric PCE984265C is a versatile CPU module designed to offer efficient control in various automation systems. Its compact design and high-performance features make it ideal for integration into a wide range of applications.

Key Features

• Model: PCE984265C
• Manufacturer: Schneider Electric
• Product Line: CPUs
• Product Type: CPU Module
• Power Supply Input Voltage: 120/230 VAC
• Power Supply Output Voltage: 24 VDC
• Rated Current: 1 A
• Communication Protocols: MODBUS, MODBUS PLUS
• Status Indication: LED indicators
• Memory: 16K Logic, 32K Data, 2X MB
• Operating Temperature: 0°C to 60°C

Technical Specifications

• Dimensions: 105 mm (W) x 180 mm (H) x 265 mm (D)
• Weight: 1.8 lbs (0.816 kg)
• Power Input Voltage: 120/230 VAC
• Frequency: 50/60 Hz
• Input Phases: Single-phase
• Memory:
  • 16K for Logic
  • 32K for Data
  • 2X MB for additional storage
• Communication Protocols: MODBUS and MODBUS PLUS
• Operating Temperature: 0°C to 60°C
• Status Indication: LED lights for real-time system status monitoring

Description

The Schneider Electric PCE984265C CPU module is built for efficiency in automation control. Its compact design allows for easy integration into existing systems, making it ideal for space-constrained applications. This module supports a wide input voltage range of 120/230 VAC, providing flexibility across various industrial settings. The 1-phase power supply and 50/60 Hz frequency compatibility make it versatile for different regions and operational needs.

With 16K of logic memory and 32K of data memory, the PCE984265C efficiently processes tasks while ensuring quick data retrieval and storage. Additionally, the module supports MODBUS and MODBUS PLUS communication protocols, ensuring smooth integration with other devices in the system. The LED indicators provide real-time status updates, helping users to monitor the system easily and troubleshoot issues when necessary.

This module operates within a temperature range of 0°C to 60°C, making it suitable for a variety of industrial environments, including those with moderate environmental conditions. Weighing just 1.8 lbs (0.816 kg), it is both lightweight and reliable, delivering optimal performance without taking up excessive space.

Applications

• Industrial Automation: Perfect for controlling automated processes in factories and manufacturing plants.
• Building Management Systems: Ideal for controlling HVAC, lighting, and security systems.
• Energy Management: Helps optimize energy usage in large-scale industrial and commercial applications.
