Schneider Electric PC-O984-145 CPU Module

The Schneider Electric PC-O984-145 is a high-performance CPU module designed specifically for the TSX COMPACT series. This module offers reliable processing power, supporting a range of industrial control applications. It features a compact design with a memory capacity of 8 KB, capable of processing up to 8K instructions, and includes an integrated Modbus communication port for seamless data exchange.

Key Features

Memory Capacity:
The provides 8 KB of memory, enabling the handling of 8K instructions, making it suitable for moderate-sized control applications.
Modbus Communication Port:
This module comes equipped with a Modbus communication port, ensuring efficient data transfer and compatibility with other industrial devices in your system.
Rack-Mountable Design:
Designed for rack mounting, the PC-O984-145 simplifies installation into the TSX COMPACT series chassis, offering a stable and secure setup.
Durability & Resilience:
Built to withstand challenging industrial environments, the PC-O984-145 is resistant to 1 gn of vibration with 0.75 mm displacement and shock resistance of 15 gn for 11 ms. This makes it highly durable for industrial settings with potential mechanical disturbances.
Temperature and Humidity Range:
The module operates efficiently in temperatures from 0 to 60 °C, withstanding a wide humidity range of 5% to 95% (non-condensing). It can also store data at temperatures ranging from -40 to 85 °C.
Compact and Lightweight:
With a weight of 0.35 kg, the module is light and easy to integrate into existing systems, making installation and maintenance straightforward.

Applications

The PC-O984-145 is suitable for a variety of industrial applications within the TSX COMPACT series. It is ideal for automation, process control, and machinery management, supporting efficient data processing and communication within industrial networks.

Technical Specifications

Parameter	Value
Manufacturer	Schneider Electric
Model	PC-O984-145
Product Type	CPU Module
Product Line	TSX COMPACT
Memory Capacity	8 KB
Program Memory	8K instructions
Mounting Type	Rack-mounted
Status LEDs	Yes
Communication Port	1 x Modbus
Memory Banks	1 MB x 1 MB+
Vibration Resistance	1 gn, 0.75 mm displacement
Processor Type	984-based CPU
Operating Voltage	5 V DC
Shock Resistance	15 gn, 11 ms
Operating Temperature	0 to 60 °C
Humidity Range	5 to 95% (non-condensing)
Storage Temperature	-40 to 85 °C
Weight	0.35 kg
