Schneider Electric DAW 105 Input Module

The Schneider Electric DAW 105 is an input module designed to deliver precise and reliable signal processing. As part of Schneider Electric’s robust range, the DAW 105 enables seamless integration within industrial automation systems, ensuring optimized performance across various applications.

Key Features

Precision Signal Processing: The DAW 105 reliably handles discrete inputs, ensuring the accuracy of your industrial signals.
Wide Compatibility: This module supports numerous industrial sensors, enhancing flexibility for various control systems.
Efficient Power Usage: Despite its high performance, the DAW 105 consumes minimal power, making it energy efficient.
Compact and Durable: With its space-saving design, it fits easily into industrial environments and endures challenging conditions.
Easy Integration: It works seamlessly with other Schneider Electric products, ensuring smooth system integration and control.

Technical Specifications

Parameter	Details
Manufacturer	Schneider Electric
Product Type	Discrete Input Module
Product Line	DAW Series
Part Number	DAW 105
Weight	0.65 kg (1.43 lbs)
Input Voltage Range	24 V DC
Number of Inputs	16
Input Type	Discrete (Binary)
Input Signal Type	24 V DC positive
Input Impedance	20 kΩ per input
Operating Temperature	0°C to 60°C (ambient, non-condensing)
Storage Temperature	-20°C to 70°C
Humidity Range	0% to 95% non-condensing
Protection Rating	IP20
Power Consumption	1.2 W
Module Format	Standard DIN rail mount

Applications

The Schneider Electric DAW 105 input module is ideal for environments requiring dependable input signal management. You can find this module in a variety of applications, including manufacturing control, process automation, and other industrial fields where precise input handling is essential.

About Schneider Electric

Schneider Electric leads in energy management and automation solutions. Their DAW series, which includes the represents a commitment to precision and reliability in industrial applications. With a focus on efficiency and seamless integration, Schneider Electric products enhance the functionality of control systems worldwide.
