The Schneider Electric 490NRP25400 serves as a high-performance fiber optic repeater designed specifically for Modicon systems. It leverages fiber optic cables to ensure smooth and reliable data transmission, particularly in Modbus Plus networks. By enhancing communication, this module supports critical applications where signal integrity is essential.
Key Features of the Schneider Electric 490NRP25400
- Efficient Data Transmission: The 490NRP25400 transmits data at a rate of 1 Mbit/sec, using Bi-Phase S encoded data over fiber optic cables. This guarantees fast, accurate communication.
- Versatile Power Supply: You can operate this repeater using either 115/230 VAC or 24 VDC, which accommodates a wide range of power setups.
- Line/Drop Transceiver: Equipped with a line/drop transceiver, it facilitates bus and line drop configurations for Modbus Plus applications.
- Flexible Mounting Options: Mount the device easily on a panel or shelf, allowing for quick installation in various system setups.
- Reliable Connectivity: Use a 9-pin “D” connector for electrical interface, while ST-type connectors ensure secure optical connections.
- Temperature Resilience: With an operating temperature range of 0°C to 60°C and a storage range of -40°C to 85°C, the device operates effectively in harsh environments.
Technical Specifications of the Schneider Electric 490NRP25400
| Specification | Value |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon |
| Part Number | 490NRP25400 |
| UPC | 785901795438 |
| Product Type | Fiber Optic Repeater |
| Network | Modbus Plus |
| Medium | Fiber Optic |
| Line/Drop Transceiver | Yes |
| Application | Bus and Line Drop |
| Mounting Method | Panel or Shelf |
| Power (Nominal) | 115/230 VAC, 24 VDC |
| Data Rate | 1 Mbit/sec |
| Electrical Interface | Modbus Plus via 9-pin “D” connector |
| Optical Interface | ST-type Connectors |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Weight | 1.81 kg (4.00 lbs) |
Why Choose the Schneider Electric 490NRP25400?
The 490NRP25400 ensures reliable communication in Modbus Plus networks by utilizing fiber optic cables for data transmission. Thanks to its high data rate of 1 Mbit/sec, it meets the demands of real-time data exchange in critical automation systems. Additionally, its line/drop transceiver provides versatility for complex configurations, making it ideal for bus and line drop applications.
This device’s flexible mounting options enable effortless installation in any setup. You can easily place it on a panel or shelf to save space and simplify system integration. With a wide temperature range and resilience to high humidity, the 490NRP25400 delivers consistent performance in both controlled and challenging environments.
By supporting Modbus Plus communication, the 490NRP25400 enhances the reliability and efficiency of your system. It fits seamlessly into your existing network, offering a robust, long-lasting solution for fiber optic communication.
