Schneider Modicon Quantum 140DDO35310 Discrete Output Module In Stock

The Schneider Electric Modicon Quantum 140DDO35310 is a high-performance DC discrete output module designed for demanding automation systems. With 32 outputs and negative logic (sink), this module ensures fast switching, strong protection, and reliable operation in industrial environments.

Key Features of 140DDO35310

Belongs to the Modicon Quantum automation platform.
Provides 32 DC outputs, grouped in 4 groups of 8 channels.
Operates at 24 V DC with voltage limits between 19.2 and 30 V.
Supports negative logic (sink) configuration for field devices.
Delivers a response time ≤ 1 ms, ensuring precise control.
Equipped with internal output fuses for safe and stable performance.

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Range	Modicon Quantum
Model	140DDO35310
Output Type	DC discrete, 32 channels
Grouping	4 groups of 8
Logic Type	Negative logic (sink)
Addressing	2 output words
Voltage Range	19.2–30 V DC
Absolute Max Voltage	50 V for 1s pulse
Max Load Current	16 A per module, 4 A per group
Surge Current	5 A for 1 ms
Voltage Drop	<0.4 V at 0.5 A
Leakage Current	0.4 mA at 30 V
Max Tungsten Load	12 W at 24 V
Fault Indication	Field power loss, blown fuse
Fuse Rating	3 A each point, 5 A per group
Isolation (Bus/Channel)	1780 Vrms DC for 1 minute
Isolation (Group)	500 Vrms DC for 1 minute
Power Dissipation	2.0 W + (0.4 V × load current)
Signaling	1 green LED (bus active), 1 red LED (fault), 32 green LEDs (status)
Bus Current	330 mA
Module Format	Standard
Certifications	CE, FM Class 1 Div 2, RINA, GOST, C-Tick, RMRS
Standards	UL 508, CSA C22.2 No.142

Environmental and Physical Data

Specification	Details
Operating Temperature	0…60 °C (32…140 °F)
Storage Temperature	-40…85 °C (-40…185 °F)
Relative Humidity	95% non-condensing
Altitude	Up to 5000 m (16404 ft)
Resistance to ESD	4 kV contact, 8 kV air (IEC 801-2)
Resistance to EM Fields	9.1 V/m, 80–2000 MHz (IEC 801-3)
Net Weight	0.45 kg (0.99 lb)
Package Dimensions	31.2 × 4.5 × 16.3 cm (12.28 × 1.77 × 6.42 in)
Shipping Weight	0.486 kg (17.1 oz)

Why Choose 140DDO35310?

The 140DDO35310 module offers fast, reliable output switching for critical automation tasks. Its strong protection features, wide certification coverage, and compact design make it suitable for industries requiring maximum reliability.
